System Service Mode
005 Low Speed
[OPC Drum Rev Time]
2902
Adjusts the time for how long the OPC drum motor reverses after job end. DFU
001 All: BW
002 All: FC
003 DevRev: FC
004 DevRev: Bk
[ImageTrunsferRevTime]
2904
Adjusts the time for how long the image transfer belt motor reverses after job
end. DFU
003 All
[Drum Stop Angle]
2906
DFU
001 Color
002 Bk
[GainAdj:TransferM] Gain Adjustment of Image Transfer Belt Motor
2908
DFU
001 120 mm/sec
002 60 mm/sec
D037/D038/D040/D041
*ENG [0 to 120 / 5 / 1sec /step]
*ENG
[0to 200 / 60 / 10 msec/step]
*ENG [0to 200 / 50 / 10 msec/step]
*ENG [0to 200 / 70 / 10 msec/step]
*ENG
[0to 200 / 200 / 10 msec/step]
*ENG
[0 to 200 / 50 / 10 msec/step]
*ENG
[0 to 359 / 0 / 1 deg/step]
*ENG
[0 or 1 / 0 / 1/step]
*ENG 0: GAIN: High speed
1: GAIN: Low speed
[0 or 1 / 1 / 1/step]
*ENG
0: GAIN: High speed
9-108 SM Appendix
