Printer Service Mode

9.2 PRINTER SERVICE MODE
9.2.1 SP1-XXX (SERVICE MODE)
1001 Bit Switch
001 Bit Switch 1
bit 0 DFU
bit 1 DFU
bit 2 DFU
bit 3 No I/O Timeout
Enable: The MFP I/O Timeout setting will have no effect. I/O Timeouts will
never occur.
bit 4
SD Card Save Mode
Enable: Print jobs will be saved to an SD Card in the GW SD slot (
Save Function" in the System Maintenance Reference of the Field Service
Manual).
bit 5 DFU
bit 6 DFU
bit 7 [RPCS,PCL]: Printable area frame border
Enable: The machine prints all RPCS and PCL jobs with a border on the
edges of the printable area.
1001 Bit Switch
002 Bit Switch 2
bit 0 DFU
bit 1 DFU
D037/D038/D040/D041
0: Disable
0: Disable
0: Disable
9-356
0 1
- -
- -
- -
1: Enable
1: Enable
"Card
- -
- -
1: Enable
0 1
- -
- -
SM Appendix
