15. As soon as the printer receives the data, it will be stored on the SD card automatically
with no print output. Nothing is displayed on the screen, indicating that a Card Save
operation was successful.
16. Press "Offline" and then the "Clear/Stop" button to exit Card Save mode.
17. Change the Bit Switch Settings back to the default 00000000. Press the "#" button in
the numeric keypad to register the changes.
18. Remove the SD card after the main power switch is turned off.

For D037/D040

1.
Turn the main power switch OFF.
SM
5-39
Card Save Function
D037/D038/D040/D041
