VTech VSP600A Quick Start Manual page 10

To install the base station:
1. Plug one end of the Ethernet cable into the Ethernet port on the rear of the base
station (marked by
router or switch.
2. If the base station is not using power from a PoE-capable network router or switch:
a. Connect a compatible VTech power adapter (purchased separately
distributor or dealer
b. Plug the power adapter into an electrical outlet that is not controlled by a wall
switch.
To electrical outlet
(if not using PoE)
IMPORTANT INFORMATION
1. Use only a compatible VTech power adapter.
2. The power adapter is intended to be correctly oriented in a vertical or floor mount
position. The prongs are not designed to hold the plug in place if it is plugged into
a ceiling, under-the-table or cabinet outlet.
To mount the base station on a wall:
1. Install two mounting screws on the wall. Choose screws with heads
larger than 5 mm (3/16 inch) in diameter (1 cm / 7/16 inch diameter
maximum). The screw centers should be 5 cm (1 15/16 inches)
apart vertically or horizontally.
2. Tighten screws until only 3 mm (1/8 inch) of the screws are
exposed.
), and plug the other end of the cable into your network
) to the base station power jack.
Use only
Supplied
Adapter
RESET
10
from your
