Description of parts

Right side and rear side

1 2
POWER
ON
OFF
1 POWER switch (Page 19)
2 START/STOP button (Page 25)
 REC CHECK button (Page 25)
 Zoom button (Page 30)
 HANDLE ZOOM switch (Page 30)
6 Recording enable/disable switch (Page 40)
7 Handle zoom button (Page 30)
8 Handle START/STOP button (Page 25)
9 Built-in stereo microphone (Page 51)
10 Tally lamp (Front) (Page 19)
11 Remote control sensor (Front) (Page 18)
1 White balance sensor (Page 39)
3 4 5 6 7 8 9 10 11 12
13 14
15
18 20 22
19 21 23
13 INPUT 1/2 (audio input) switch (Page 51)
1 Zoom ring pin hole (Page 30)
15 P2 card access lamp (x 2) (Page 26)
16 Viewfinder (Page 20)
17 P2 card/SD memory card slot (cover)
(Pages 25 and 29)
18 SCENE FILE dial (Page 53)
19 SLOT SEL button (Page 44)
0 Mode button (Page 25)
1 Remote control sensor (Rear) (Page 18)
 Tally lamp (Rear) (Page 19)
 Mode lamp (Page 25)
 Power terminal (Page 16)
 Battery release button (Page 16)
16 17 2 1
24
25
11
