Page 1: Installation Instructions
Installation Instructions for Stacked Washer/Dryers Original Instructions Keep These Instructions for Future Reference. (If this machine changes ownership, this manual must accompany machine.) Part No. 804671R2 www.speedqueen.com September 2014... -
Page 3: Front Matter
Front Matter Front Matter WARNING WARNING WARNING • Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any Risk of fire. Highly flammable material. other appliance. W881 • WHAT TO DO IF YOU SMELL GAS: •... - Page 4 Front Matter WARNING • Installation of unit must be performed by a quali- fied installer. • Install clothes dryer according to manufacturer’s instructions and local codes. • DO NOT install a clothes dryer with flexible plas- tic venting materials. If flexible metal (foil type) duct is installed, it must be of a specific type identified by the appliance manufacturer as suita- ble for use with clothes dryers.
-
Page 5: Table Of Contents
Table of Contents Front Matter..................3 Dimensions..................... 6 Installation..................... 9 Before You Start.....................9 Tools......................9 Parts Included..................... 9 Removing Dryer..................9 Reassembling Dryer..................9 Order of Installation Steps................9 Position Unit Near Installation Area............... 10 Remove Shipping Materials................10 Connect Fill Hoses..................11 Water Supply Requirements............... -
Page 6: Dimensions
Dimensions Dimensions Electric Models SWD1003N_SVG * 66.06 in. [1678 mm] * 56.97 in. [1447 mm] 23.5 in. [597 mm] 8.375 in. [213 mm] 24 in. [610 mm] 8 in. [203 mm] 15.4 in. [391 mm] * 36.9 in. [938 mm] * 14.5 in. - Page 7 Dimensions * With leveling legs turned into base. NOTE: Exhaust openings are 4 inch [102 mm] metal ducting. Gas Models SWD1004N_SVG 1. 3/8 in. NPT Gas Connection *66.06 in. [1678 mm] *56.97 in. [1447 mm] 23.5 in. [597 mm] 8.375 in. [213 mm] 24 in.
- Page 8 Dimensions *13.1 in. [333 mm] * With leveling legs turned into base. NOTE: Exhaust openings are 4 inch [102 mm] metal ducting. © Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT Part No. 804671R2...
-
Page 9: Installation
Installation Installation Before You Start WARNING Tools Any disassembly requiring the use of tools must be For most installations, the basic tools you will need are: performed by a suitably qualified service person. W299 Parts Included An accessories bag has been shipped inside your unit. It includes: •... -
Page 10: Position Unit Near Installation Area
Speed Queen will not cover scheduled repair serv- ices where the installation requirements are not per specifica- tions, nor can products be returned to the authorized dealer in these cases. -
Page 11: Connect Fill Hoses
Installation Water Supply Requirements Water supply faucets must fit standard 3/4 inch [19 mm] female garden hose couplings. DO NOT USE SLIP-ON OR CLAMP- ON CONNECTIONS. NOTE: Water supply faucets should be readily accessi- ble to permit turning them off when washer is not being used. -
Page 12: Risers
Installation color-coded hose from the hot water faucet goes to the water mixing valve marked “H” and the blue color-coded hose from the cold faucet goes to the valve marked “C”. Refer to Figure Figure 6 . 6. Then, using a pliers, screw approximately 1/4 turn. IMPORTANT: DO NOT cross thread or overtighten couplings. -
Page 13: Wall Installation
Installation 2. Remove the beaded tie-down strap from accessories bag and place around standpipe and drain hose and tighten strap to hold hose to standpipe. Refer to Figure 8 . This will prevent the drain hose from dislodging from drain receptacle during use. - Page 14 Installation Natural Gas Altitude Adjustments WARNING Altitude Orifice Size Part To reduce the risk of gas leaks, fire or explosion: feet [m] inches [mm] • The dryer must be connected to the type of gas 10,000 [3050] 0.0785 [1.99] 503781 as shown on nameplate located in the door re- cess.
-
Page 15: Electric Dryer Only - Connect Electrical Plug
Installation NOTE: The dryer and its appliance main gas valve must Earth/Ground Information be disconnected from the gas supply piping system during any pressure testing of that system at test pres- This dryer must be properly connected to protective earth/ground sures in excess of 1/2 psi [3.45 kPa]. - Page 16 Installation L1 L2 L1 L2 D816I_SVG 1. A typical 30-Amp Three-Wire Receptacle NEMA Type 10-30R 2. 120 ± 12 V.A.C. 3. 240 ± 12 V.A.C. 4. Intermediate Fuse Box (may be omitted if service entrance box is fused) 5. Wall Receptacle 6.
-
Page 17: Connecting Power Cord With Four-Wire Plug
Installation 3. Use a strain relief and insert end of power cord through power supply hole. D696I_SVG Figure 14 4. Use the three screws from the accessories bag to attach the power cord wires to the terminal block. Refer to Figure 15 . DRY2016N_SVG 3-Wire Connection 1. - Page 18 Installation 4-Wire Connection DRY2468N_SVG 1. Earth/Ground Screw Figure 18 4. Use a strain relief and insert end of power cord through power supply hole. DRY2482N_SVG 1. Neutral Terminal 2. “L2” Terminal 3. Black 4. White 5. Earth/Ground 6. Red 7. “L1” Terminal 8.
-
Page 19: Connect Dryer Exhaust System
Installation Connect Dryer Exhaust System WARNING To reduce the risk of fire and combustion gas accu- mulation the dryer MUST be exhausted to the out- doors. W604 WARNING To reduce the risk of fire and the accumulation of combustion gases, DO NOT exhaust dryer air into a window well, gas vent, chimney or enclosed, unven- tilated area, such as an attic, wall, ceiling, crawl SWD997N_SVG... -
Page 20: Exhaust Direction
Installation • Exhausting dryer in hard-to-reach locations can be done by Dryer is shipped from factory ready for rear exhaust. installing 521P3 Flexible Metal Vent Kit (available as option- Exhausting the dryer through sides or bottom can be accomplish- al equipment at extra cost). ed by installing a Directional Exhaust Kit, 528P3, available as •... - Page 21 Installation Dryer and Exhaust Duct Clearances WARNING Minimum Units elevated above floor level must be anchored to Area Description Clearance that elevated surface, base or platform. The material used to elevate the unit should also be anchored to * Rear clearance is minimum. 6 inches [152 mm] are the floor to ensure that the unit will not walk or that recommended when venting through rear of unit.
-
Page 22: Wipe Out Inside Of Washer And Dryer Drums
Installation SWD1013N_SVG SWD1029N_SVG Figure 24 1. Level Plug In the Washer and Dryer 2. Wood Block 3. Rubber Foot 4. Leveling Leg Electric Dryer 5. Locknut 6. Unit Base Connect the dryer to an electrical power source. Refer to Connect Electrical Plug section for information on connecting power cord. - Page 23 Installation Plug Cord Into Separately Fused 15 Amp Circuit WARNING To reduce the risk of fire, electric shock, serious in- jury or death, all wiring and grounding MUST con- form with the latest edition of the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1, and such local regulations as might apply.
-
Page 24: Washer
Installation WARNING WARNING This unit is equipped with a three-prong (earth/ To reduce the risk of fire, electric shock, serious in- ground) plug for your protection against shock haz- jury or death, all wiring and protective earth/ground ard and should be plugged directly into a protective connections MUST conform with the latest edition of earth/ ground three-prong receptacle. -
Page 25: Check Installation
Installation led and connected to a protective earth/ground in accordance with Standard 120 Volt, 60 Hertz 3-Wire Effective Earth/ all local codes and ordinances. Ground Circuit WARNING Improper connection of the equipment earth/ground conductor can result in a risk of electric shock. Check with a qualified electrician or service person if you are in doubt as to whether the unit is properly connected to a protective earth/ground. -
Page 26: Electric Dryers
Installation Electric Dryers 1. Close the loading door and start the dryer in a heat setting (re- fer to the operation instructions). 2. After the dryer has operated for three minutes, the exhaust air or exhaust pipe should be warm. Gas Dryers IMPORTANT: This operation is to be conducted by qualified personnel only. -
Page 28: Installer Checklist
Installer Checklist Installer Checklist Fast Track for Installing the Stacked Washer/Dryer Position Unit Near Installation Area. Connect Dryer Exhaust System. CHECK CHECK SWD997N_SVG1 Remove the Shipping Ma- Position and Level the terials and Install Plugs. Washer. CHECK CHECK FLW2359N_SVG SWD1029N_SVG1 Connect Fill Hoses.
