Keypad Programming

Keypad Zone Number Assignment
Step Action
1 [ ] + [
ENTER INSTALLER CODE
(default: 0000 / 000000)
2
Press and hold
3 [ ] + [
ZONE NUMBER
Entry Point Zone Assignment (StayD)
Step Action
1 [ ] + [
ENTER INSTALLER CODE
(default: 0000 / 000000)
2 Press and hold [
OFF
3 [ ]*
ZONE NUMBER
4 [ ]
ENTER
Keypad Input/Output Configuration (K636 V2.0 and higher)
Step Action
1 [ ] + [
ENTER INSTALLER CODE
(default: 0000 / 000000)
2 Press and hold [
ARM
3 Option [1]
4 Option [2]
When configuring as an output, you must first clear the keypad zone (if assigned).
Magellan / Spectra SP
Details
] [ ] + [ ] = flash. [
ARM STAY
[ ] + [ ] = on
ARM STAY
(3sec)
]* K32I / K32 / K32LCD= 2 digits: 01 to 32
ENTER
K636 / K10V/H = 1 digit: 1 to 0(10)
* To erase a keypad zone number, press [
EOL resistors if section [706] option [2] is enabled (see page 24).
Details
] [ ] + [ ] = flash.
ARM STAY
] (3sec) [ ] + [ ] = on
ARM STAY
K32I / K32RF / K32IRF / K32 / K32LCD = 2 digits: 01 to 32
K636 / K10V/H = 1 digit: 1 to 0(10)
* The first zone you program will be the designated entry point and will flash. Up to three
more path zones can be added; these zones will light up and stay lit.
Press [ ] to save and exit
ENTER
Details
] [ ] + [ ] = flash.
ARM STAY
] (3sec) [ ] + [ ] = on
ARM STAY
ON = Output switches to ground following system arming (Blue wire 150mA max.).
OFF = Input (Keypad zone input)
ON = Output N.O.
OFF = Output N.C.
] may also be used.
MAINTENANCE CODE
], then [
CLEAR
]. Also, this step activates the
ENTER
22
