in the figure and make sure it is fastened properly (see figure).
44• To open the hood, push the braces downwards. The hood can
be lowered along with the reclining backrest.
45• To tighten to hood, lower the hinge on the inside as indicated
in the figure.
46• Extend the hood completely, unzipping the zipper, figure B.
The hood follows the backrest's incline.
47• The hood can easily be transformed into a sun canopy, see
figure. Zip the zipper up and block the hook with its practical
hook.
48• To remove the hood from the Navetta bassinet unit,
disconnect it from the cover at the sides. Disconnect eyelets A
and B from the lining as shown in the figure, press the tongue
on both sides and disconnect the hood.
49• To remove the hood from the stroller, press the tab as
indicated in figure A, from both sides of the hood.
Unhook and pull up as indicated in figure B.
NAVETTA BASSINET UNIT
HANDLEBAR
50• To raise the handlebar, pull it up until it clicks into place. The
handlebar is locked only when it is in the vertical position and
the two blocks have been inserted in their housings.
51• To lower the handlebar, release it by pushing up the two
blocks and then push the handlebar downward.
52• The handlebar makes it easier to carry and hook the bassinet
unit onto the chassis and strollers.
POSITION OF ROCKER AND CRIB
53• The Navetta base is specially shaped so it will rock when set
on a flat surface.
54• The Navetta can be turned into a small, non-swinging cradle
by folding down the built-in legs, as shown in the figure.
ADJUSTING THE BACKREST
55• The height of the backrest can be adjusted by pulling it up
and turning the handle, as shown in the figure.
ADJUSTING THE AIR CIRCULATION
56• The Navetta base features holes that can be opened to allow
air to flow into it from below.
To open the holes in the front of Navetta (the side where the
hood is located), push the two hooks toward the outside.
57• To open the holes from the rear (the side opposite the hood),
push one of the two hooks toward the outside.
REMOVABLE LINING
58• To remove the lining, disconnect the eyelets on the sides and
undo it from the front.
59• Remove the 2 tongues from the bodywork and take it off.
ATTACHING AND REMOVING THE BASSINET UNIT ON THE
STROLLER
The Navetta bassinet unit is equipped with the Ganciomatic
System, which can fasten to the Pilko P3 stroller's Ganciomatic
fastenings.
60• To detach the bassinet unit from the stroller, push the handle
(on the opposite side from the hood) sideways then upwards,
while lifting the bassinet unit by the handle.
USING NAVETTA IN THE CAR
61• Navetta is designed to turn into Navetta AUTO when you use
the two hooks (shown in the figure) together with the special
Auto Kit that is available for purchase separately.
ON TRACK MODULAR SYSTEM DETAILS
COVER
62• To fasten the cover to the stroller, zip it onto the footboard as
shown in the figure.
Do up the two buttons, as in figure B, to fasten the cover.
RAIN CANOPY
63• To attach the rain canopy, zip it to the hood.
64• Fasten the button found on the elastic to the stroller button
until you hear a click, as indicated in the figure.
65• Fasten the elastic on the bottom of the rain canopy to the
wheel.
66• The practical rain canopy can be lowered by opening the
zipper; it will remain fastened to the stroller by the elastic.
67• This rain canopy has been designed for use with the Primo
Viaggio car seat fastened on the stroller as well, to guarantee
your child total protection.
• Do not use the rain canopy in closed places. Always check
from time to time to make sure the child is not too hot.
• Do not place the PVC rain canopy near sources of heat. Keep
cigarettes away from the rain canopy.
• Make sure the rain canopy does not get caught in any
moving mechanism on the chassis or stroller.
• Always remove the rain canopy before folding up the chassis
or stroller.
• Clean the rain canopy with a sponge and soapy water. Do not
use harsh detergents.
SAFETY BELT
68• Make sure that the strap has been correctly inserted as shown
in Figure A. Fasten the safety belt as shown in Figure B.
69• To unfasten the safety belt, press the sides of the buckle
(Figure A) and pull the waist belt outwards (Figure B).
70• The new safety belt is easier to wear, thanks to the "snap
open and shut" system. Before attaching the safety belt,
attach the small buckle to the backrest by inserting the tab
into the special holder, as shown in the figure. Next, fasten
the safety belt on your child, and then detach the belt
from the backrest to allow the child more freedom of
movement. The small buckle should be placed below the
child's shoulders.
ADJUSTING THE BACKREST
71• The backrest reclines in four different positions. To recline the
backrest, lift the handle (Figure A) while lowering the backrest
(Figure B), stopping at the desired position. To raise the
backrest, pull it upwards.
REMOVABLE LINING
72• To remove the lining from the stroller, unhook the sack
fasteners from the armrests, as shown by the arrows.
73• Unbutton the sack from the seat, and slip it off the hooks on
the footboard.
74• Unbutton the side buttons on the sack, as shown in the
figure. Slip the safety belt leg divider out from under the seat.
75• Unbutton the buttons on the sack from the seat, and slip
the sack off the hooks on the footboard. Slip the sack off the
bottom of the stroller.
PLIKO P3 STROLLER with the
GANCIOMATIC SYSTEM
The Ganciomatic system is a practical, fast way to fasten the
Navetta bassinet unit and the Primo Viaggio car seat – which are
both equipped with the Ganciomatic system - to the Pliko P3
stroller, using the Ganciomatic hooks.
GANCIOMATIC HOOKS ON THE STROLLER
76• To raise the Ganciomatic hooks on the stroller, lift the sack in
the corners of the seat and turn the two hooks upwards until
they click into place.
77• To lower the Ganciomatic hooks on the stroller, pull the lever
outwards while turning the hooks downwards, as shown in
the figure.
PLIKO P3 + NAVETTA
78• To fasten the Navetta bassinet unit to the stroller, it is
necessary to first:
- Set the brakes on the stroller;
- Completely lower the backrest on the stroller;
- Raise the Ganciomatic hooks on the stroller;
- Remove the front bar and insert the caps to close the stroller
armrests;
- Lift the stroller footboard to its highest position;
- Hold the Navetta bassinet unit by its handle;
- Place the bassinet unit on the Ganciomatic hooks on the
stroller, keeping the head of the bassinet unit on the opposite
side from the stroller handlebars;
- Press down with both hands on the sides of the Navetta
