MBT-5003 L-Band Up/Down Converter System
Appendix A
Command
Arguments
Parameter
(Instruction
for Command
Type
Code and
or Response
Qualifier)
Retrieve Next
N/A
variable length
5
unread stored
Statistics
Remote Baud
SBR=
4 bytes
Rate
Description of Arguments
(Note that all arguments are ASCII numeric codes
to Query
Query only.
Unit returns the oldest 5 Stored Statistics entries which have not
yet been read over the remote control. Reply format: {CR}Sub-
body{CR}Sub-body{CR}Sub-body{CR}Sub-body{CR}Sub-body,
where Sub-body=
ddmmyyhhmmssaaa.abbb.bccc.cddd.dee.eeff.ffghijkk.kll.l
ddmmyy = day/month/year
hhmmss = hour:minute:second
aaa.a = Conveter A Operating Temperature
bbb.b = Conveter B Operating Temperature
ccc.c = Converter A RF Power output
ddd.d = Converter B RF Power output
ee.ee = Converter A Attenuation Setting
ff.ff = Converter B Attenuation Setting
g = Converter A Mute On/Off
h = Converter B Mute On/Off
i = Converter A Online/Offline Status
j = Converter B Online/Offline Status
kk.k = Converter A Tuning Voltage
ll.l = Converter B Tuning Voltage
If there are less than 5 entries to be retrieved, the remaining
positions are padded with zeros.
If there are no new entries, the response is RNS*.
Command or Query.
Set remote baud rate as follows:
2400 = 2400 baud
4800 = 4800 baud
9600 = 9600 baud
19K2 = 19200 baud
38K4 = 38400 baud
Default Value: 9600
Example: <1/SBR=9600'cr'
>0001/SBR=9600'cr''lf'
Note: When changing baud rates remotely the response to the
command will be returned using the same baud rate as that used
to send the command.
between 48 and 57)
A–15
Response to
Query
Command
(Instruction
(Target to
Code and
controller)
qualifier)
N/A
RNS?
RNS={CR}Sub-
body{CR}Sub-
body{CR}Sub-
body{CR}Sub-
body{CR}Sub-body
(See Description of
Arguments)
SBR=
SBR?
SBR=xxxx
SBR?
(Same format as command
arguments)
Revision 1
MN-MBT5003
Response to query
(Target to controller)
