Appliance Preparation

A. Top Vent
Figure 7.1 Remove the cover plate by removing the four
screws holding it to the top of the appliance. Remove and
discard the cover plate.
Figure 7.2 Remove the center insulation plug.
Figure 7.3 Cut the metal retaining band and fold the sides
out.
Figure 7.4 Fold the center parts of the retaining band up
and use to remove the vent cap.
Figure 7.5 Discard the vent cap, remove and discard
the insulation basket. Note: Once the vent cap has been
removed it cannot be reattached.
Proceed to Section 7. C.
Heat & Glo • Infi nity • 2003-900 Rev. N • 2/10
CAUTION
Sharp Edges
• Wear protective gloves and safety
glasses during installation.
Note: Actual fi replace top appearance may be different from
pictures shown above.
