Heat & Glo Infinity Owner's Manual

Hide thumbs Also See for Infinity:
Table of Contents

Advertisement

Quick Links

Model:
Infi nity
• Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
This appliance may be installed as an OEM installation in
manufactured home (USA only) or mobile home and must be
installed in accordance with the manufacturer's instructions
and the manufactured home construction and safety standard,
Title 24 CFR, Part 3280 or Standard for Installation in Mobile
Homes, CAN/CSA Z240MH, in Canada.
This appliance is only for use with the type(s) of gas indicated
on the rating plate.
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Heat & Glo • Infi nity • 2003-900 Rev. N • 2/10
Owner's Manual
• Leave this manual with
party responsible for use
and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
fi replace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other fl ammable
materials.
• Keep clothing, furniture, draperies and other fl ammable
materials away.
This appliance has been supplied with an integral barrier
to prevent direct contact with the fi xed glass panel. DO
NOT operate the appliance with the barrier removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fi tter.
See Table of Contents for location of additional Commonwealth
of Massachusetts requirements.
Installation and service of this appliance should be
performed by qualifi ed personnel. Hearth & Home
Technologies suggests NFI certifi ed or factory trained
professionals, or technicians supervised by an NFI
certifi ed professional.
Installation and Operation
1

Advertisement

Table of Contents
loading

Related Manuals for Heat & Glo Infinity

Summary of Contents for Heat & Glo Infinity

  • Page 1 Owner’s Manual Installation and Operation Model: Infi nity NOTICE DO NOT DISCARD THIS MANUAL • Important operating • Read, understand and follow • Leave this manual with a n d m a i n t e n a n c e these instructions for safe party responsible for use instructions included.
  • Page 2 Read this manual before installing or operating this appliance. Please retain this owner’s manual for future reference. Congratulations Congratulations on selecting a Heat & Glo gas appliance This Owner’s Manual should be retained for future —an elegant and clean alternative to wood burning reference.

  • Page 3: Table Of Contents

    Table of Contents 1 Listing and Code Approvals 9 Gas Information A. Appliance Certifi cation ......4 A.

  • Page 4: Listing And Code Approvals

    Models Maximum Orifi ce locations such as in bathrooms or near sinks. Input BTU/h Size (DMS) (U.S. or Canada) 35,000 (0-2000 FT) INFINITY (NG) CANADA 31,500 (2000-4500 FT) Heat & Glo • Infi nity • 2003-900 Rev. N • 2/10...

  • Page 5: Requirements For The Commonwealth Of Massachusetts

    Inspection Note: The following requirements reference various The state or local gas inspector of the side wall horizon- Massachusetts and national codes not contained in this tally vented gas fueled equipment shall not approve the document. installation unless, upon inspection, the inspector ob- serves carbon monoxide detectors and signage installed H.

  • Page 6: Getting Started

    Getting Started A. Design and Installation Considerations C. Inspect Appliance and Components Heat & Glo direct vent gas appliances are designed to WARNING operate with all combustion air siphoned from outside of the building and all exhaust gases expelled to the outside. Inspect appliance and components for damage.

  • Page 7: Framing And Clearances

    Framing and Clearances WARNING Note: • Illustrations reflect typical installations and are FOR Fire Risk DESIGN PURPOSES ONLY. Provide adequate clearance: • Illustrations/diagrams are not drawn to scale. • Around air openings • Actual installation may vary due to individual design preference.

  • Page 8: Constructing The Appliance Chase

    B. Constructing the Appliance Chase unfaced insulation. If the appliance is being installed on a cement surface, a layer of plywood may be placed under- A chase is a vertical boxlike structure built to enclose the neath to prevent conducting cold up into the room. gas appliance and/or its vent system.

  • Page 9: Mantel Projections

    D. Mantel Projections 1/2 NON-COMBUSTIBLE CEILING MATERIAL TOP VIEW 2-1/2 in. UNLIMITED Note: Clearance from opening to perpendicular wall that extends past the front edge of fi replace. Figure 3.4 Clearances to Mantel Legs or Wall Projections (Acceptable on both sides of opening.) TOP FRONT EDGE OF FIREPLACE F.

  • Page 10: Termination Locations

    Termination Locations A. Vent Termination Minimum Clearances B. Vent Termination For Horizontal Terminations - The trapezoidal cap SLP- TRAP1 and SLP-TRAP2 are the only caps that are ap- WARNING proved to terminate a horizontal vent run. Fire Risk. For Horizontal Terminations - To attach and secure the Explosion Risk.
  • Page 11 Figure 4.2 specifi es minimum vent heights for various HORIZONTAL pitched roofs. OVERHANG 2 FT. 2 FEET MIN. VERTICAL MIN. WALL LOWEST 6 in. (minimum) up to 20 in. 18 in. minimum DISCHARGE 152 mm/508 mm 457 mm OPENING 20 in. and over 0 in.
  • Page 12 Electrical Service (See Note 2) Measure vertical clearances from this surface. (3 FT.) H or i Measure horizontal clearances from this surface. = VENT TERMINAL = AIR SUPPLY INLET = AREA WHERE TERMINAL IS NOT PERMITTED = 12 inches....clearances above grade, veranda, J** = 7 ft.

  • Page 13: Vent Information And Diagrams

    Vent Information and Diagrams A. Vent Table Key The abbreviations listed in this vent table key are used in the vent diagrams. Symbol Description Vertical First section (closest to appliance) of vertical length Second section of vertical length First section (closest to appliance) of horizontal length 8-1/2 in.

  • Page 14: Outside Air

    D. Outside Air CAUTION Install fresh air intake in the same pressure zone as the exhaust pipe termination cap. Failure to do so may cause over-heating after the unit is shut down, potentially resulting in damaged components. COMBUSTION DUCT COLLAR FOR WARNING AK-CFX AIR KIT Figure 6.
  • Page 15 STRAIGHT UP VERTICAL VENTING V (FT.) 40’ MAX. (12.4 m) Figure 8. Straight Up Vertical Venting Heat & Glo • Infi nity • 2003-900 Rev. N • 2/10...

  • Page 16: Vent Clearances And Framing

    Vent Clearances and Framing A. Pipe Clearances to Combustibles B. Wall Penetration Framing Combustible Wall Penetration WARNING Whenever a combustible wall is penetrated, you must frame a hole for the wall shield fi restop. The wall shield Fire Risk. fi restop maintains minimum clearances and prevents cold Explosion Risk.

  • Page 17: Vertical Penetration Framing

    C. Vertical Penetration Framing A ceiling fi restop MUST be used between fl oors and attics. • Frame opening 9 in. x 9 in. (229 mm x 229 mm) whenever the vent penetrates a ceiling/ fl oor (see Figure 6.3). ATTIC ABOVE •...

  • Page 18: Install Attic Insulation Shield

    D. Install Attic Insulation Shield BEND ALL TABS INWARD 90° WARNING! Fire Risk. DO NOT allow loose materials or TO MAINTAIN CLEARANCE insulation to touch vent. Hearth & Home Technologies AND PREVENT INSULATION FROM FALLING INSIDE Inc. requires the use of an attic shield. The National Fuel Gas Code ANSI Z223.1 and NFPA 54 requires an attic shield constructed of 26 gauge minimum metal that extends at least 2 in.

  • Page 19: Appliance Preparation

    Appliance Preparation A. Top Vent Figure 7.1 Remove the cover plate by removing the four screws holding it to the top of the appliance. Remove and discard the cover plate. Figure 7.4 Fold the center parts of the retaining band up and use to remove the vent cap.

  • Page 20: Securing And Leveling The Appliance

    B. Securing and Leveling the Appliance WARNING Fire Risk. • Prevent contact with sagging, loose insulation. • Do NOT install against combustible materials such as exposed insulation, plastic and insulation backer. The diagram shows how to properly position, level, and secure the appliance (see Figure 7.6).

  • Page 21: Installing Vent Pipe

    Installing Vent Pipe A. Assemble Vent Sections To attach the fi rst vent component to the starting collars of the appliance: • Lock the vent components into place by sliding the pipe section onto the collar. • Align the seam of the pipe and seam of collar to allow engagement.

  • Page 22: Assemble Slip Sections

    B. Assemble Slip Sections C. Secure the Vent Sections • Slide the inner fl ue of the slip section into the inner fl ue • Vertical runs of SLP pipe must be supported every 8 ft. of the pipe section and the outer fl ue of the slip section (2.44 m).

  • Page 23: Disassemble Vent Sections

    D. Disassemble Vent Sections • Lower the support box through the hole in the roof until its bottom is at least 2 in. (51 mm) below the ceiling (Figure • Rotate either section (see Figure 8.7) so the seams on 8.9).

  • Page 24: Install Metal Roof Flashing

    F. Install Metal Roof Flashing • See minimum vent heights for various pitched roofs (Figure 8.11) to determine the length of pipe to extend CAULK through the roof. • Slide the roof fl ashing over the pipe sections extending through the roof as shown in Figure 8.12. HORIZONTAL OVERHANG 2 FT.

  • Page 25: Install Vertical Termination Cap

    H. Install Vertical Termination Cap J. Heat Shield Requirements for Horizontal Termination • Attach the vertical termination cap by sliding the inner collar of the cap into the inner fl ue of the pipe section WARNING! Risk of Fire! To prevent overheating and fi re, while placing the outer collar of the cap over the outer heat shields must extend through the entire wall thick- fl...

  • Page 26: Install Horizontal Termination Cap

    K. Install Horizontal Termination Cap Note: When using termination caps with factory-supplied heat shield attached, no additional wall shield fi restop is WARNING! Risk of Fire! The telescoping fl ue section of required on the exterior side of a combustible wall. the termination cap MUST be used when connecting vent.

  • Page 27: Gas Information

    Gas Information A. Fuel Conversions C. Gas Connection Before making gas connections ensure that appliance be- Note: Have the gas supply line installed in accordance ing installed is compatible with the available gas type. with local building codes, if any. If not, follow ANSI Any natural or propane gas conversions necessary to 223.1.
  • Page 28 • Ensure that gas line does not come in contact with outer HIGH ALTITUDE INSTALLATIONS wrap of appliance. Follow local codes. U.L. Listed gas appliances are tested and approved without • Incoming gas line should be piped into the valve requiring changes for elevations from 0 to 2000 feet in the compartment and connected to the 1/2 inch connection U.S.A.

  • Page 29: Electrical Information

    Electrical Information A. Recommendation for Wire D. Intellifi re Ignition System Wiring This appliance requires that continuous 110-120 VAC be This appliance requires a 110 VAC supply to the appliance wired to the factory installed junction box. Maintain cor- junction box for operation. A wiring diagram is shown in rect polarity when wiring the junction box.
  • Page 30 INTERMITTENT IGNITION PILOT IGNITOR MODULE 3 VAC PLUG-IN 3V TRANSFORMER LOW VOLTAGE SEE NOTE 1 HIGH TEMP IGNITION SWITCH MODULE (3V) GROUND TO FIREPLACE CHASSIS VALVE LOW VOLTAGE RELAY SEE NOTE 1 GROUND REMOTE CONTROL HOT NEUTRAL HIGH LIMIT SWITCH REMOVE THESE CONNECTORS TO WIRE SWITCHES OPTIONAL...

  • Page 31: Junction Box Installation

    BATTERIES LEAVE AS FACTORY WIRED REAR VIEW (BLACK) DO NOT (RED) (GREEN) (ORANGE) (BLACK) (RED) DO NOT VALVE MODULE (BROWN) (BROWN) FRONT VIEW (BROWN) (BROWN) (RED) (BLACK) FLAME SOLENOID 3V ADAPTOR PLUG DO NOT (ORANGE) FLAME HIGH/LOW (ORANGE) (BLACK) LEAVE PLUGGED PLUG TO JUNCTION BOX CONNECTION...

  • Page 32: Finishing

    11 11 Finishing A. Mantel Projections FINISH WALL MATERIAL MAY BE COMBUSTIBLE Figure 11.1 shows the minimum vertical and correspond- - TOP AND SIDES ing maximum horizontal dimensions of appliance mantels or other combustible projections above the top front edge of the appliance.

  • Page 33: Appliance Setup

    Appliance Setup A. Remove Shipping Materials E. Lava Rock, Vermiculite, Rockwool/Ember Placement Remove shipping materials from inside or underneath the fi rebox. WARNING B. Clean the Appliance Clean/vacuum any sawdust that may have accumulated Explosion Risk. inside the fi rebox or underneath in the control cavity. •...

  • Page 34: Positioning The Logs

    F. Positioning the Logs Log Set Assembly: LOGS-INFINITY CAUTION: Logs are fragile! Denotes Flat Spots Carefully remove the logs from the packaging. Place logs on a piece of cardboard as shown in Figure 1. The logs will be assembled in a similar orienta- tion to their positions in Figure 1.
  • Page 35 LOG #3 (SRV2003-704): Place log #3 on the front right of the grate. The two grooves on the bottom of the log and the narrow end of the log line up with the 1 , and 3 grate tines on the right of the grate. LOG #4 (SRV2003-703): Place log #4 on the front left of the grate.
  • Page 36 LOG #6 (SRV2003-706): Place log #6 on top of log #5, #1, and #3. The left end sits on the fl at spot of log #5 and the right end sits on log #3. The “branch” rests on the fl at spot of log #1. LOG #7 (SRV780-707): Place log #7 on top of log #1 and #5.

  • Page 37: Glass Assembly

    G. Glass Assembly H. Grilles and Trim Install optional marble and brass trim surround kits as de- WARNING sired. Marble, brass, brick, tile, or other noncombustible materials can be used to cover up the gap between the Handle glass doors with care. sheet rock and the appliance.

  • Page 38: Operating Instructions

    Operating Instructions A. Before Lighting Appliance WARNING The gas control system used with this model is an Inter- mittent Pilot Ignition (IPI). This system includes a 3V con- HOT SURFACES! Glass and other surfaces are hot during trol valve, electronic module and intermittent pilot. operation AND cool down.

  • Page 39: Lighting Instructions (Ipi)

    B. Lighting Instructions (IPI) The IPI system may be operated with two D-cell batteries. When using batteries, unplug the transformer. To prolong battery life, remove them when using the transformer. FOR YOUR SAFETY LIGHTING READ BEFORE LIGHTING INSTRUCTIONS (IPI) WARNING: If you do not follow these instructions exactly, a fi re or explosion 1.

  • Page 40: After Appliance Is Lit

    C. After Appliance is Lit CAUTION Initial Break-in Procedure • Prevent accidental appliance operation when not When you light the appliance, you may notice that it pro- attended. duces heat which does have an associated odor or smell. • Unplug or remove batteries from remote control if absent If you feel this odor is excessive it may require the initial or if appliance will not be used for an extended period of time.

  • Page 41: Troubleshooting

    Troubleshooting With proper installation, operation, and maintenance your gas appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist a qualifi ed service person in the diagnosis of a problem and the corrective action to be taken.
  • Page 42 Intellifi re Ignition System - (continued) Symptom Possible Cause Corrective Action 3. (Continued) Pilot lights c. Module is not grounded. Verify that module is securely grounded to metal chassis but continues to spark, of appliance. Verify that wire harness is fi rmly connected to and main burner will not module.

  • Page 43: Maintaining And Servicing Appliance

    Maintaining and Servicing Appliance Although the frequency of appliance servicing and maintenance will depend on use and the type of installation, a qualifi ed service technician should perform an appliance checkup at the beginning of each heating season. CAUTION WARNING Handle glass assembly with care.

  • Page 44: Maintenance Tasks

    A. Maintenance Tasks Inspect Maintenance Tasks Doors, Surrounds 1. Assess condition of screen and replace as necessary. Recommend addition of screen if one is not present. and Fronts 2. Inspect for scratches, dents or other damage and repair as necessary. 3.

  • Page 45: Reference Materials

    Reference Materials A. Appliance Dimension Diagram Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 3. ØM ACCESS ELECTRICAL ACCESS Location Inches Millimeters Location Inches Millimeters 22-3/16 38-1/4 35-1/4 11-1/8 19-1/2 23-13/16 35-3/4 6-5/8 8-7/16...

  • Page 46: Vent Components Diagrams

    B. Vent Components Diagrams 6-1/2 in. 165 mm 6-1/2 in. 165 mm 6-1/2 in. 8-3/4 in. 165 mm 222 mm 9-1/4 in. 6 in. 235 mm 152 mm 6-5/8 in. 168 mm SLP45 6-5/8 in. 45° Elbow 168 mm 9-7/8 in. 251 mm SLP90 90°...
  • Page 47 5 in. (302 mm) (127 mm) 13-7/8 in. (352 mm) SLP-WT-BK VPK-INFINITY DVP-BEK2 Wall Thimble-Black Vinyl Siding Protect Kit DVP-HPC Cap Brick Extension Figure 16.3 SLP Series Vent Components Heat & Glo • Infi nity • 2003-900 Rev. N • 2/10...

  • Page 48: Service Parts

    D. Limited Lifetime Warranty Heat & Glo • Infi nity • 2003-900 Rev. N • 2/10...
  • Page 49 D. Limited Lifetime Warranty (continued) Heat & Glo • Infi nity • 2003-900 Rev. N • 2/10...

  • Page 50: Contact Information

    E. Contact Information Heat & Glo, a brand of Hearth & Home Technologies Inc. 7571 215th Street West, Lakeville, MN 55044 www.heatnglo.com Please contact your Heat & Glo dealer with any questions or concerns. For the location of your nearest Heat & Glo dealer, please visit www.heatnglo.com.
