440 PRO X Fan
MODEL: . . . . . . . . . .
MODEL NUMBER: . S03NX4FS
ENGINE MODEL: . . EC45PM040
ELECTRICAL
Flywheel I.D. . . . . . . IG3792
CDI Marking . . . . . . . CU7235
Alternator Output . . . 240 Watts @ 4000 RPM
Ignition Timing . . . . . 28 BTDC@3000RPM 1.5
9 BTDC@75000RPM 1.5
Spark Plug / Gap . . . NGK BR9ES / 0.028" (0.7mm)
Lights: Head . . . . . . 2 60 High/55 Low
Tail . . . . . . . . 2@3 watts
Brake . . . . . . 18 watts
Voltage Regulator . . LR7
Electric Start . . . . . . . N/A
SUSPENSION / CHASSIS
Body Style . . . . . . . . Pro X
Front Suspension . . Pro X
IFS Shocks . . . . . . . . Ryde FXt
IFS Spring Rate . . . . 90/180#/in.
Front Spring Preload 2.8 Thread Adjust
Front Vertical Travel 9.22 (23.4 cm..)
Rear Suspension . . . Pro X
Rear Travel . . . . . . . . 13.9 (35.3 cm..)
Ryde FX t
Front Track Shock . .
Spring Rate . . . . . . . . 190#/in.
Rear Track Shock . . Ryde FXt IFP Clicker
Rear Springs . . . . . . .347 / 77
Track Type . . . . . . . . 15 x121 x.82 (38.1x307.34x2.08cm..)
Track Tension . . . . . .
1 1/2" (38mm) slack with 10# (4.54kg) weight 16" (40.64cm..) ahead of rear idler shaft
OPTIONAL REAR TORSION SPRINGS
440 Pro X Fan Rear Torsion Springs
SOFT
.347 (sq.) diameter/77
L.H . 7042159--067
R.H. 7042160--067
(STD)
.347 (sq.) diameter/77
L.H. 7042101-067
R.H. 7042102--067
GENERAL INFORMATION
CAPACITIES
Fuel Tank . . . . . . . . . . 11.8 Gal. (45.4 L)
Oil Tank . . . . . . . . . . . . 3.5 Quarts (3.3 L)
Coolant . . . . . . . . . . . . N / A
Chaincase Oil . . . . . . . 8 oz.
CHAINCASE
Sprockets / Chain . . . 21:41, 74 P HYVO
Reverse . . . . . . . . . . . . Option
Brake Pads . . . . . . . . . HayesType 81
Chaincase Center Dist.7.92" (20.12cm.)
Driveshaft Sprockets . 2 Drivers
Brake Type . . . . . . . . . Polaris HPB
FIRM
.359 (sq.) diameter/77
L.H. 7042157--067
R.H. 7042158--067
1.5
