ASSEMBLY

Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the
packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the
included hex keys and your own Phillips screwdriver
rubber mallet
Use the drawings below to identify the small parts used for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following
the key number is the quantity needed for assembly. Note: Some small parts may have been preassembled.
If a part is not in the hardware kit, check to see if it has been preassembled.
23mm Wave
Washer (83)–2
Wave Washer
(43)–2
M8 x 45mm Button Bolt (50)–4
M8 x 25mm Patch
Screw (56)–2
M10 x 74mm Button Bolt (28)–2
.
M10 Split Handlebar Washer
Washer (59)–7
M10 Nylon Locknut
(33)–6
M10 x 25mm Button
Screw (67)–3
, adjustable wrench
M10 Washer
(55)–2 (78)–2
M4 x 16mm
Screw (52)–4
M8 Nylon Locknut
(38)–4
M10 Bolt Set (74)–2
M10 x 27mm Patch
Screw (40)–2
M10 x 75mm Carriage Bolt (34)–4
5
, and
Spring Bracket
Washer (35)–2
M4 x 19mm
Screw (26)–2
M10 x 30mm
Carriage Bolt (80)–2
