10 Configuration and Use - CIP & IP Routing
Assigning CIP PVCs to
CIP members
Deleting CIP entries
114 / 238
Proceed as follows:
1. Browse to the 'CIP' page.
Assignment of a CIP PVC is performed in the 'CIP
Connections' table.
2. Select the phonebook entry from the 'Dest' pop down list.
Note: In case the presented phonebook entries do not suite your desired
configuration, you must firstly create a correct phonebook entry. See
section 11.3 for more information.
3. Depending the RFC1577/RFC2225 compliancy of the remote
access router, the following must be filled in, in the 'Remote
address' field:
Compliancy
YES
NO
4. Click
On the 'CIP' page, click
interface you want to delete. As a result your selection is deleted.
Click
.
Remote IP address
You don't have to fill in anything; the InATMARP reply will
implicitly assign the PVC to the CIP member.
You must fill in the exact IP address of the remote access
router; the PVC is explicitly assigned to the CIP member.
and
to finish the procedure.
next to the CIP connection or CIP
3EC 17059 ABAA TCZZA Ed. 01
