Troubleshooting
See Table 6 for display messaging. Refer to the
TEC Series Wireless Thermostat Controller System
Technical Bulletin (LIT-12011414) for troubleshooting
details.
Accessories
All the accessories in Table 7 include mounting
hardware; contact the nearest Johnson Controls
representative to order any of these parts.
Table 6: Display Messages
Display
Function
Service
Indicates that there is a service alarm in accordance with the programmable Binary Input (BI2).
Filter
Indicates that the filter(s) is dirty in accordance with the programmable Binary Input (BI2).
Window
Indicates that an outside window or door is open and has cancelled the thermostat controller heating or
cooling action in accordance with the programmable Binary Input (BI1).
Table 7: Accessories (Order Separately)
Code Number
Description
ACC-INSL-0
Foam Insulation Pad Kit (10 adhesive-backed foam pads)
SEN-600-1
Remote Indoor Air Temperature Sensor
SEN-600-4
Remote Indoor Air Temperature Sensor with Occupancy Override and LED
1
Duct Mount Air Temperature Sensor
TE-6361M-1
TE-636S-1
Strap-Mount Temperature Sensor
1.
Additional TE-636xx-x Series 10k ohm Johnson Controls Type II Thermistor Sensors are available; refer to the
TE-6300 Series Temperature Sensors Product Bulletin (LIT-216320) for more details.
12
TEC2045-2 Wireless Thermostat Controller with Single Proportional Output and One-Speed Fan Control
Installation Instructions
Note: Review the technical specifications of the
accessories prior to their use in an application.
Repair Information
If the TEC2045-2 Wireless Thermostat Controller fails
to operate within its specifications, replace the unit. For
a replacement thermostat controller, contact the
nearest Johnson Controls representative.
