Configuring the Wireless Mesh Network Settings
Use the following process to configure the wireless
mesh network.
1. Select a PAN ID and Channel. Use these same
values for every TEC Wireless Thermostat
Controller (and the associated TEC20 Coordinator)
on the same wireless mesh network. See Table 5.
Table 5: Installer Configuration Menu (Part 1 of 4)
Parameter Description and Default
Appearing
on Display
Com addr Wireless address at the thermostat
controller; Default: 4
PAN ID Sets the Personal Area Network
Identification (PAN ID) of the
wireless network. All devices on a
network must have the same
PAN ID setting to communicate with
each other. Default: 0
Channel Sets the mesh network channel the
device uses for communication.
Only devices using the same mesh
network channel can communicate
with each other. Default: 10
GET FROM Parameter not available at this time.
BI1 Configuration of Binary Input 1.
Default: None
8 TEC2045-2 Wireless Thermostat Controller with Single Proportional Output and One-Speed Fan Control
Installation Instructions
2. Select a Com Address for each TEC Wireless
Thermostat Controller (1 to 254). This address
must be unique to each TEC Wireless Thermostat
Controller on the same wireless network (that is,
unique to the PAN ID/Channel combination). See
Table 5.
After configuring the wireless mesh network settings,
refer to the TEC Series Wireless Thermostat Controller
System Technical Bulletin (LIT-12011414) for directions
on integrating the TEC Wireless Thermostat
Controllers and TEC20 Coordinator with a supervisory
controller.
Selection Options
Range: 000 to 254
Addresses of each item on the wireless bus must be uniquely
numbered, increasing from 1.
Note: Setting this parameter to 0 disables the function.
Range: 0 to 500
Note: Setting this parameter to 0 disables the function.
Range: 11 to 26
Note: Setting this parameter to 10 disables the function.
N/A
(None): No function is associated with an input.
(Rem NSB): Remote Night Setback (NSB) via a time clock input, an
occupancy sensor, or from a voltage-free contact.
Contact open = Occupied; contact closed = Unoccupied.
(MotionNO*): Temporary occupancy request via a motion detector
input. Contact open = Unoccupied. When the contact closes, the
thermostat controller goes into the occupied mode for a specified
TOccTime. Once the TOccTime begins, the thermostat controller
remains in the occupied mode if the contact is open, until the
TOccTime expires.
(MotionNC*): Temporary occupancy request via a motion detector
input. Contact closed = Unoccupied. When the contact opens, the
thermostat controller goes into the occupied mode for a specified
TOccTime. Once the TOccTime begins, the thermostat controller
remains in the occupied mode if the contact is closed, until the
TOccTime expires.
(Window**): Cancels the heating or cooling action when a window
is open. A Window alarm is displayed indicating that the window
needs to be closed to resume heating or cooling.
* These settings disable any local override function.
**When this setting is selected, the heating and/or cooling outputs
are enabled only when the contact is closed.
