Johnson Controls TEC2045-2 Installation Instructions Manual page 10

Table 5: Installer Configuration Menu (Part 3 of 4)
Parameter Description and Default
Appearing
on Display
Lockout Selectable Lockout Levels for
limiting end user keypad interaction.
Default: 0
SeqOpera Determines the sequence of
operation.
Default: 1
Unocc HT Sets the Unoccupied Heating
setpoint value.
Default: 62.0°F/16.5°C
Unocc CL Sets the Unoccupied Cooling
setpoint value.
Default: 80.0°F/26.5°C
Heat max Sets the Occupied and Unoccupied
maximum Heating setpoint values.
Default: 90.0°F/32.0°C
Cool min Sets the Occupied and Unoccupied
minimum Cooling setpoint values.
Default: 54.0°F/12.0°C
Set type Provides the option of temporarily
changing the heating or cooling
setpoint by pressing the UP/DOWN
arrow keys.
Default: permnent
TOccTime Sets the duration of the Temporary
Occupancy Time when the heating
or cooling setpoints in the Occupied
mode are established by:
• an Override Function enabled in
the Main User Menu (when the
thermostat controller is in the
Unoccupied mode)
• a temporary heating or cooling
setpoint
Default: 2.0 hrs
DoorTime Engages the Unoccupied mode if
the door stays open minimally for
the time specified.
Default: 2.0 min
10 TEC2045-2 Wireless Thermostat Controller with Single Proportional Output and One-Speed Fan Control
Installation Instructions
Selection Options
Lockout
Level
Mode Fan
Setting Setting
(0) Access Access
(1) Access Access
(2) No Access No Access
(3) No Access No Access
(4) No Access No Access
(5) No Access No Access
(0): Cooling Only (Off-Cool). The default is Cool.
(1): Heating Only (Off-Heat). The default is Heat.
(2): Cooling and Reheat (Off-Auto*-Heat-Cool). The default is Heat.
(3): Heating and Reheat (Off-Heat). The default is Heat.
* Auto can be disabled with the AutoMode parameter.
Note: Choose the selection option (0): Cooling Only when using a
changeover sensor to allow changeover to occur between Cooling
Only and Heating Only.
Range: 40.0°F/4.5°C to
90.0°F/32.0°C
Range: 54.0°F/12.0°C to
100.0°F/37.5°C
Range: 40.0°F/4.5°C to
90.0°F/32.0°C
Range: 54.0°F/12.0°C to
100.0°F/37.5°C
(temporar): Local changes to the heating or cooling setpoints are
temporary, and remain effective for the specified TOccTime.
(permnent): Local changes to the heating or cooling setpoints are
permanently stored in the thermostat controller memory.
Range: 0.0 to 24.0 hrs in 1-hour increments
Range: 1.0 to 10.0 min
Function
Local Occupied
Override Temperature
Setpoints
Access Access
No Access Access
Access Access
No Access Access
Access No Access
No Access No Access
Note: When adjusting the
temperature, press the UP/
DOWN arrow keys to
change the temperature in
0.5F°/0.5C° increments;
press and hold the
UP/DOWN arrow keys
to change the temperature
in 5.0F°/5.0C° increments.
