Summary of Contents for NetComm 3G42W-M
- Page 4 WAN Interface DC-HSPA+ x 1 (Up to 42Mbps Downlink/5.76 Mbps Uplink) Network Standards Supports quad-band UMTS/HSDPA/HSUPA (850/900/1900/2100MHz) Antenna Type Internal 3G antenna with SMA connector for optional external antenna LAN Interface Ethernet x 4 WLAN IEEE 802.11n backward compatible with 802.11b/g USB 2.0 ports 2 x USB2.0 ports for Print Server/Mass Storage Power...
- Page 5 Quick Start Guide Wireless Security Card User Manual on CD Ethernet Cable Power Supply...
- Page 6 SIM Slot: Mobily SIM card goes in this slot LAN ports: 4 Ethernet ports to allow Wired connections Reset button: To factory default the device Power connector: Connect the power supply to power up the device External Antenna connector: SMA connector to connect an optional external antenna...
- Page 7 Signal Strength LED: Indicates your connection to the Wireless Service Provider (Carrier). Signal strength ranges from High, Medium & Low. Network Connection LED: Indicates whether you are connected via the 2G or the 3G network. Ethernet Connection LED: Indicates which of the 4 LAN ports are active. www LED: Indicates whether your Internet connection is active.
- Page 8 Connecting via cable (wired) 1. Connect the yellow Ethernet cable to one of the yellow ports at the back of the router 2. Connect the other end of the yellow Ethernet cable to your computer. 3. Wait 30 seconds for the connection to establish. 4.
- Page 9 Advanced Configuration 1. For advanced configuration, open your browser (eg. Internet Explorer, Safari) 2. Enter the address of your Router (Default: http://192.168.1.1/) 3. When prompted for your Username and Password enter: Username: admin Password: admin...
- Page 10 Wireless 42Mbps router Using DC-HSPA+ technology and NetComm’s unique design to give you up to 42Mbps downlink and 5.6Mbps uplink speeds Built-in 11n WiFi Covers 55 metres in every direction and gives you speeds up to 300Mbps Cable Management Side cover ensures that your cables stay in order...
- Page 11 For customers who need to freely move their high speed internet connection with them 3G42W-M can be shared Customers who discover they cannot share their wireless USB modem with family, friends or colleagues and need a device that will allow...
- Page 12 Having trouble accessing the Internet? 1. Check if the SIM is inserted at the back of the unit 2. Make sure that the device is powered ON. 3. You should see 5 LED’s ON - Power LED, one of the Signal Strength LED’s, either the 2G or the 3G LED, the www LED and the Wi-Fi LED.
- Page 13 Having trouble connecting Wirelessly? 1. Check if the WiFi LED is ON. 2. Make sure you are connected to the right Wireless Network and have entered the password correctly. If all else fails, take a PIN and hold the RESET button at the back of the unit down for 10 seconds to set the unit to its factory defaults and try again.
