Page 1: Table Of Contents
AT2005USB Instruction Manual AT2005USB Cardioid Dynamic USB/XLR Microphone Contents Introduction & features Setting up your microphone with stand clamp & desk stand Preliminary setup with Mac OS X Preliminary setup with Windows XP Preliminary setup with Windows Vista Preliminary setup with Windows 7... - Page 2 Compliance with FCC rules (USA only) This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC WARNING You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.
- Page 3 The AT2005USB offers high-quality articulation and intelligibility perfect for home studio recording, field recording, podcasting, voiceover, and on-stage use. Its cardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source.
-
Page 4: Setting Up Your Microphone With Stand Clamp & Desk Stand
Extend the tripod legs to provide a wide, secure base, and place the tripod desk stand on a flat surface. Install the AT2005USB microphone into the microphone mount, with ON/OFF switch up The top of the microphone should be facing the sound source. -
Page 5: Preliminary Setup With Mac Os X
Sound 4. Click the Input tab and select the AT2005USB as the device for sound input. AT2005USB Your preferences are now set to use the AT2005USB on your Mac with GarageBand or another recording program of your choice. -
Page 6: Preliminary Setup With Windows Xp
2. In the lower right portion of your screen you may see a message that new hardware was found; or you may see a driver software installation notice. 3. To select the AT2005USB as your default recording device, begin at your Start menu. - Page 7 4. Select Sounds and Audio Devices.
- Page 8 Sound recording Default device. AT2005USB 7. Through the window, you can set the computer volume or mute the microphone. Wave In AT2005USB Your preferences are now set to use the AT2005USB with Windows XP with the recording program of your choice.
-
Page 9: Preliminary Setup With Windows Vista
(You should see a green check mark beside the USB microphone icon.) Microphone SigmaTel C-Major Audio Working Microphone AT2005USB Working Your preferences are now set to use the AT2005USB with Windows Vista with the recording program of your choice. -
Page 10: Preliminary Setup With Windows 7
2. In the lower right portion of your screen you may get a message that new hardware was found; or you may see a driver software installation notice. Start menu > Control Panel > Sound To select the AT2005USB as your default recording device, begin at your Start menu. Select Control... - Page 11 4. Select Sound. 5. The following screen will pop up:...
- Page 12 (loudness). You may need to come back to this window to readjust the level after you begin recording. Your preferences are now set to use the AT2005USB with Windows 7 with the recording program of your choice.
-
Page 13: Using Headphones
Additional Information Using headphones " (3.5 mm) headphone jack on the bottom of the microphone allows you to directly monitor your recording with a pair of headphones. When your preliminary setup is completed, and your USB microphone is connected to your computer’s USB port (the microphone’s blue LED is illuminated), plug your headphones into the headphone jack on the bottom of the microphone. -
Page 14: Specifications
AT2005USB Specifications † Element: Dynamic Polar Pattern: Cardioid Frequency Response: 50 – 15,000 Hz Power Requirements: USB Power (5V DC) Bit Depth: 16 bit Sample Rate: 44.1 kHz/48 kHz Controls: On/off switch; headphone volume control Weight: 266 g (9.4 oz) Dimensions: 183.6 mm (7.23") long, 51.0 mm (2.01") maximum body diameter... - Page 15 AT2005USB To reduce the environmental impact of a multi-language printed document, product information is available online at www.audio-technica.com in a selection of languages. Afin de réduire l’impact sur l’environnement de l’impression de plusieurs, les informations concernant les produits sont disponibles sur le site www.audio-technica.com dans une large sélection de langue.
