Chapter 4 Voice Only WT4090 Remote Control

Introduction

Since the Voice Only WT4090 does not have a display, access to settings and controls must be done using a
remote display software, such as MotoRC or ActiveSync Remote Display.

MotoRC Software

Download the MotoRC application from the Zebra Support Central web site: http://www.zebra.com/support. Follow
the instructions provided with the software to install on a host computer.

Microsoft ActiveSync Remote Display Software

Download Windows Mobile Power Toys from the Microsoft web site: http://www.microsoft.com. Follow the
instructions with the software to install on a host computer.
Ensure that ActiveSync is installed on the host computer. See

Connection to Host Computer

To connect the Voice Only WT4090 to a host computer:
Connect the Single Slot Serial/USB cradle to the host computer. See
1.
setup instructions.
Insert the Voice Only WT4090 into the cradle.
2.
If ActiveSync was installed properly, the host computer automatically detects the Voice Only WT4090 and
3.
begins ActiveSync. The ActiveSync windows appears.
Select the Yes radio button to create a partnership with the host computer or select No radio button to connect
4.
as a guest.
Click Next. The Microsoft ActiveSync window indicates that it is connected to the Voice only WT4090.
5.
Chapter 3, ActiveSync for more information.
Single Slot USB Cradle on page 2-2 for
