SPECIFICATIONS*
VIDEO
Image Sensor
Total Pixels
Scanning System
Frequency
Synchronization
Horizontal Resolution
Minimum Illumination
S/N Ratio
Video Output
LENS
Focal Length
Lens Type
IR Distance
OPERATIONAL*
Shutter Speed
Backlight
Star-Light
3D-DNR
32
960H CCD
960 (H) x 478 (V)
2 : 1 Interlace
15.734KHz (H), 59.95Hz (V)
Internal or Line Lock
720 TV Lines [B/W], 700 TV Lines [Color]
F1.2 (30IRE): 0.14 Lux [Color]
F1.2 (30IRE): 0.03 Lux [B/W]
0.0 Lux (DWC-V6563DIR)
52dB (AGC off)
CVBS: 1.0Vp-p / 75 Ω
2.8~12 mm
Varifocal Auto Iris Lens
100ft Range IR (DWC-V6563DIR)
1/60s~1/120000s
OFF / ON
X2 ~ X512
OFF / Low / Middle / High
