Kodak Scan Station 100 Maintenance Manual

CLEANING THE IMAGING GUIDES AND
PAPER SENSOR
1. Remove dust and debris from this area by using a Stati-
cide wipe or a small brush. Be careful not to scratch the
imaging guides when cleaning.
2. Wipe the upper and lower imaging guides with a
Staticide wipe. (The upper imaging guide is not shown
in this illustration.)
IMPORTANT: S taticide wipes contain isopropanol which can
cause eye irritation and dry skin. Wash your
hands with soap and water after performing
maintenance procedures. Refer to the User's
Guide for MSDS acquisition.
3. Wipe the imaging guides again with an almost-dry
Staticide wipe to remove any streaks.
4. Clean the paper sensor using the almost-dry Staticide
wipe to remove any dust or streaks.
K NUMBER, SERIAL NUMBER AND
DATAPLATE LOCATION
The K Number, Serial Number and Dataplate can be found
on the bottom of the Scan Station.
To access the dataplate:
Carefully tilt the Scan Station back until you can see
•
the dataplate on the bottom of the Scan Station.
Paper sensor
SUPPLIES
CAT No.
158 1347
Imaging guide
125 1842
844 5306
174 7849
853 5981
896 5519
* Items are subject to change.
EASTMAN KODAK COMPANY
Document Imaging
Rochester, New York 14650
Kodak and Digital Science are trademarks of Eastman Kodak Company.
© Eastman Kodak Company, 2006
A-61571
*
Description
Kodak
Scan Station Portable USB Drive,
64-MB (5-Pack)
Kodak Scan Station Portable USB Drive,
128-MB (5-Pack)
USB Replacement Connector
Kodak
Feed Module
Kodak Digital Science Roller Cleaning
Pads (qty 24)
Kodak
Staticide Wipes for Scanners
(qty 144)
Kodak Scan Station 100
Maintenance
Guide
www.kodak.com
Kodak Service
1-800-822-1414
Kodak Parts Services
1-800-471-0803
1-585-724-6042
Kodak Professional Services
1-800-525-6325
