Table of Contents

See also: Owner's Manual
I.
INTRODUCTION ......................................................................................................................... 4
II.
SAFETY ......................................................................................................................................... 6
III. SPECIFICATIONS ..................................................................................................................... 9
IV. DESCRIPTION .......................................................................................................................... 11
V.
BATTERIES AND CHARGING ............................................................................................ 16
VI. OPERATION ............................................................................................................................... 21
VII. COMFORT ADJUSTMENTS................................................................................................ 23
VIII. DISASSEMBLY AND ASSEMBLY ..................................................................................... 27
IX. TROUBLESHOOTING ............................................................................................................ 31
X.
CARE AND MAINTENANCE ................................................................................................ 32
XI. WARRANTY ................................................................................................................................ 33
Celebrity
C O N T E N T S
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Celebrity and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pride Mobility Celebrity

Summary of Contents for Pride Mobility Celebrity

  • Page 1: Table Of Contents

    III. SPECIFICATIONS ........................9 IV. DESCRIPTION .......................... 11 BATTERIES AND CHARGING .................... 16 VI. OPERATION ..........................21 VII. COMFORT ADJUSTMENTS....................23 VIII. DISASSEMBLY AND ASSEMBLY ..................27 IX. TROUBLESHOOTING ......................31 CARE AND MAINTENANCE ....................32 XI. WARRANTY ..........................33 Celebrity...

  • Page 2: Introduction

    I N T R O D U C T I O N Welcome to Pride Mobility Products, Ltd. (Pride). Congratulations on the purchase of your new Pride Scooter. Your Scooter design combines the most advanced state-of-the-art components with modern, attractive styling.
  • Page 3 Name:_______________________________________________________________________________ Address:_____________________________________________________________________________ Quick Reference Information: Scooter Model:________________________________________________________________________ Serial Number:__________________________________________________________________________ Purchase Date:________________________________________________________________________ NOTE: If you ever lose or misplace your warranty card or owner’s manual, write to us and we will be glad to send you a new one immediately. Celebrity...
  • Page 4 Make certain that the seat is locked into place and that the key is removed from the key switch before getting on or off of your Celebrity, and make certain that the seat is in a locked position when you are operating your Scooter.

  • Page 5: Safety

    S A F E T Y As you begin to use your Celebrity during your daily activities, you will encounter situations that may require some practice. Simply take your time as you operate your Scooter and you will soon be in full and confident control as you maneuver through doorways, on and off of elevators, up and down ramps, and over moderate terrain.
  • Page 6 However, Pride recognizes that there will be times when you will operate your Scooter on surfaces other than concrete or asphalt. For that reason, we also designed your Celebrity to perform admirably on packed soil, grass, and gravel.

  • Page 7: Specifications

    11.5 cm (4.5") 122 cm (48") 119 cm 48 cm (47") (19") 44.5 cm (17.5") 86 cm 106.7 cm (34") (42") 61-71 cm (24"-28") 3 Wheel Turning Radius 4 Wheel Turning Radius 61 cm (24") Figure 5. Celebrity Specifications Celebrity...
  • Page 8 Batteries: 11 kg (25 lbs) each (12 volt, 32AH) Front-to-rear Lockup: Lock pin and cam lever system Ground Clearance: 11.5 cm (4.5 in) Cane/crutch holder, walker holder, rearview mirror, cup holder, power seat, oxygen bottle holder, Optional Accessories: rear basket, canopy Celebrity...
  • Page 9 VII. “Comfort Adjustments.” Power Seat Switch (Optional) If your Celebrity is equipped with a power seat, this switch enables you to raise and lower the seat. For power seat adjustment directions, see VII. “Comfort Adjustments.” WARNING! Strict adherence to the following safety rules is vital:...

  • Page 10: Description

    Use these buttons to turn on the left and right turn signal (amber) lights. n Push the appropriate turn signal button once to illuminate the signal light prior to turning your Celebrity. Your Celebrity’s turn signals are timed to shut off automatically.
  • Page 11 Celebrity. The anti-tip wheels are at the rearmost part of your Celebrity. See figures 8 and 9. Refer to VIII. “Disassembly and Assembly” for instructions on removing the rear shroud.
  • Page 12 NOTE: For your safety, use only the supplied onboard battery charger. Main Circuit Breaker When the voltage in your Celebrity’s batteries becomes low or your Scooter is heavily strained because of excessive loads, the main circuit breaker may trip to protect your Celebrity’s motor and electronics from damage.
  • Page 13 Celebrity out of freewheel mode. Anti-tip Wheels The anti-tip wheels are an integral and important safety feature of your Celebrity. WARNING! Do not remove your Scooter’s anti-tip wheels or modify your Scooter in any way that is not authorized by Pride .

  • Page 14: Batteries And Charging

    5-amp charging system. See figure 8. Two important points to remember are: n Charge your Celebrity’s batteries with the supplied onboard battery charger prior to using it for the first time. n Keep your batteries fully charged to keep your Celebrity running smoothly.
  • Page 15 3. Plug both the two-pin battery harnesses into the adjoining harnesses extending from the electronic controller module on the utility tray. See figure 10. 4. Extend the charger power cord and plug it into the wall outlet. We recommend you charge your Celebrity’s batteries for 8 to 14 hours.
  • Page 16 “full day” of service. We recommend you charge your Celebrity’s batteries for 8 to 14 hours after daily use. n If you use your Celebrity once a week or less, charge its batteries at least once a week for 12 to 14 hours at a time.
  • Page 17 88% of their peak performance level. 2. Operate your new Celebrity in familiar and safe areas. Drive slowly at first, and do not travel too far from your home or familiar surroundings until you have become accustomed to your Celebrity’s controls and have properly broken in your Scooter’s batteries.
  • Page 18 For prolonged storage, you may wish to place several boards under the frame of your Celebrity to raise your Scooter off the ground and take the weight off the tyres. This reduces the possibility of flat spots developing on the areas of the tyres contacting the ground.

  • Page 19: Operation

    7. Release the throttle lever to decelerate and come to a complete stop. The electric brake automatically engages when your Scooter comes to a stop. 8. To move in reverse, use your thumb to push the left throttle control lever to disengage your Celebrity’s brakes and move rearward.
  • Page 20 5. Carefully get out of the seat and stand to the side of your Scooter. 6. You may, if you wish, leave the seat facing to the side to facilitate boarding your Scooter the next time you are going to operate it. Celebrity...
  • Page 21 The seat can be repositioned to one of five different heights. See figure 12. 1. Remove the seat from your Celebrity. See VIII. “Disassembly and Assembly.” 2. Use the attached ring to pull and remove the ball detent pin from the seat post tower.

  • Page 22: Comfort Adjustments

    A D J U S T M E N T S FRONT-TO-BACK SEAT ADJUSTMENT The Celebrity is equipped with a sliding seat that is operated like an automobile seat. You can reposition the Celebrity’s seat forward or rearward. 1. Pull out the front-to-back seat release lever. See figure 13.
  • Page 23 Figure 14. Armrest Height Adjustment POWER SEAT ACTUATOR (OPTIONAL) Your Celebrity may be equipped with a power seat actuator. The actuator raises and lowers the seat automatically. See figure 15. WARNING! The power seat actuator is intended for operation only while the vehicle is stationary and on a level surface.
  • Page 24 6. Release the lever when you have attained your desired height. 7. Ensure your seat is in the lowest position and toggle off the power seat switch before you attempt to drive your Scooter again. SEAT ACTUATOR Figure 15. Power Seat Actuator (Optional) Celebrity...

  • Page 25: V I I I . D I S A S S E M B L Y A N D A S S E M B L Y

    1. Place the freewheel lever in the drive (down) position. 2. Push and hold down the seat lock lever to unlock it and lift the seat up and off of the Celebrity. See figure 16. 3. Gently lift the rear shroud off of the Celebrity. See figure 17. You will not be able to completely remove the rear shroud because of the rear light harness connection.
  • Page 26 Figure 18. Unplugging the Rear Light Harness Figure 19. Unplugging the Front-to-Rear Connector 6. Unplug both 2-pin battery harnesses and lift both batteries off of the Celebrity. See figures 20 and 21. CAUTION! Failing to unplug both battery harnesses and the front-to-rear connector prior to further disassembly could result in permanent damage to your Celebrity.
  • Page 27 10. Grab the handle grip on the tiller, pull upward on the release lever, and gently lower the tiller down to the center of the Celebrity chassis until it is fully lowered. 11. Remove the ball detent pins and lift the locking cam levers. See figures 24 and 25.
  • Page 28 10. Plug the large 9-pin white plastic connector from the front section of the Celebrity into the mating plug found on the control assembly cover on the utility tray at the rear of your Scooter.

  • Page 29: Troubleshooting

    Obtain a battery load tester at most any automotive parts store; follow the directions supplied with the load tester. If you experience any problems with your Celebrity that you are not able to solve, immediately contact your authorized Pride provider for information, maintenance, and service.

  • Page 30: Care And Maintenance

    CONSOLE, CHARGER, AND ELECTRONIC CONTROLLER MODULE: n Keep these areas away from moisture. n Let any of these areas dry thoroughly before operating your Celebrity if they have been exposed to moisture. STORAGE: n Refer to “How should I store my Celebrity and its batteries?” in V. “Batteries and Charging.”...

  • Page 31: Warranty

    SERVICE CHECKS AND WARRANTY SERVICE Warranty service can be performed by an authorized Pride provider. Please contact your local Pride provider for advice on the current cost affecting the service visit. Celebrity...
  • Page 32 N O T E S Celebrity...
