Summary of Contents for Pride Mobility CELEBRITY XL

  • Page 1 CELEBRITY XL...
  • Page 2 The latest/current version of this manual is available on our website. Copyright © 2009 Pride Mobility Products Corp. INFMANU3267/Rev D/August 2009...

  • Page 3: Table Of Contents

    IV. BATTERIES AND CHARGING ..................23 OPERATION ..........................28 VI. COMFORT ADJUSTMENTS ....................30 VII. DISASSEMBLY AND ASSEMBLY .................. 34 VIII. BASIC TROUBLESHOOTING ..................36 IX. CARE AND MAINTENANCE ..................... 38 WARRANTY ..........................42 APPENDIX I - SPECIFICATIONS ..................... 44 Celebrity XL www.pridemobility.com...

  • Page 4: Introduction

    I . I N T R O D U C T I O N SAFETY WELCOME to Pride Mobility Products Corp. (Pride). The product you have purchased combines state- of-the-art components with safety, comfort, and styling in mind. We are confident the design features will provide you with the conveniences you expect during your daily activities.
  • Page 5 EMI-RFI — This product has been tested and passed at an immunity level of 20 V/m. Unlocked and in freewheel mode. Place unit on level ground and stand to one side when changing from drive mode to freewheel mode or freewheel mode to drive mode. Locked and in drive mode. Celebrity XL www.pridemobility.com...
  • Page 6 Do not connect an extension cord to the AC/DC converter or the battery charger. Keep tools and other metal objects away from battery terminals. Contact with tools can cause electrical shock. Wear safety goggles. Contains Lead. www.pridemobility.com Celebrity XL...
  • Page 7 Keep your hands away from the tires when driving. Be aware that loose fitting clothing can become caught in the drive tires. Disposal and recycling — Contact your authorized Pride Provider for information on proper disposal of your Pride product and its packaging. Battery charger for indoor use only. Celebrity XL www.pridemobility.com...
  • Page 8 PRE-RIDE SAFETY CHECK Get to know the feel of your scooter and its capabilities. Pride recommends that you perform a safety check before each use to make sure your scooter operates smoothly and safely. www.pridemobility.com Celebrity XL...
  • Page 9 When driving down a ramp, keep the scooter’s speed adjustment set to the slowest speed setting to ensure a safely controlled descent. Avoid sudden stops and starts. Celebrity XL www.pridemobility.com...
  • Page 10 WARNING! Never carry an oxygen tank weighing more than 15 lbs. (6.8 kg). Never fill the front or rear basket with contents exceeding 15 lbs. (6.8 kg). 400 lbs. (181 kg) 9° (15.8%) Figure 1. Maximum Recommended Incline Angle www.pridemobility.com Celebrity XL...
  • Page 11 Regenerative: Uses electricity to rapidly slow the vehicle when the throttle control lever returns to the center/stop position. Disc Park Brake: Activates mechanically after regenerative braking slows the vehicle to near stop or when power is removed from the system for any reason. Celebrity XL www.pridemobility.com...
  • Page 12 2 in. (5 cm). Doing so could cause instability in your scooter. CURB CURB Figure 3. Correct Curb Approach Figure 4. Incorrect Curb Approach www.pridemobility.com Celebrity XL...
  • Page 13 Use your hand to turn the knob or push the handle or push-bar. Drive your scooter gently and slowly forward to push the door open. Or drive your scooter gently and slowly backward to pull the door open. Celebrity XL www.pridemobility.com...
  • Page 14 PREVENTING UNINTENDED MOVEMENT WARNING! If you anticipate being seated in a stationary position for an extended period of time, turn off the power. This will prevent unexpected motion from inadvertent throttle control lever contact. www.pridemobility.com Celebrity XL...
  • Page 15 PROHIBITED! Keep your hands away from the tires when driving. Be aware that loose fitting clothing can become caught in drive tires. Celebrity XL www.pridemobility.com...
  • Page 16 You must adhere to the following safety guidelines if you decide to smoke cigarettes while seated in your scooter. Do not leave lit cigarettes unattended. Keep ashtrays a safe distance from the seat cushions. Always make sure cigarettes are completely extinguished before disposal. www.pridemobility.com Celebrity XL...
  • Page 17 NOTE: For further information on EMI/RFI, visit the Resource Center on www.pridemobility.com. If unintended motion or brake release occurs, turn the scooter off as soon as it is safe to do so. Contact your authorized Pride Provider to report the incident. Celebrity XL www.pridemobility.com...

  • Page 18: Your Scooter

    Use these buttons to turn on the left and right turn indicator (amber) lights. See figure 5. Push the left button to activate the left turn indicator light. Push the right button to activate the right turn indicator light. The indicators are timed to shut off automatically. www.pridemobility.com Celebrity XL...
  • Page 19 These fuses help protect your scooter’s front lighting, turn indicators, and key switch console systems from receiving an overload of electrical current. The fuses used in your scooter are the same type used in auto- mobiles. See figure 7. See IX. “Care and Maintenance” for fuse replacement. Celebrity XL www.pridemobility.com...
  • Page 20 2. Push forward on the manual freewheel lever to disable the drive system and the brake system. You may now push your scooter. 3. Pull back on the manual freewheel lever to reengage the drive and the brake systems and take your scooter out of freewheel mode. www.pridemobility.com Celebrity XL...
  • Page 21 Push in the reset button to reset the breaker. If the breaker trips frequently, you may need to charge the batteries more often or have your authorized Pride Provider perform a load test on the batteries. Figure 9. Main Circuit Breaker (Reset Button) Celebrity XL www.pridemobility.com...
  • Page 22 WARNING! DO NOT leave the scooter in freewheel mode when securing it for transport. WARNING! DO NOT use your scooter as a seat in a moving vehicle. SECUREMENT POINTS SECUREMENT POINTS Figure 10. Rear Securement Points Figure 10A. Front Securement Points www.pridemobility.com Celebrity XL...

  • Page 23: Batteries And Charging

    If the battery charger is exposed to adverse or extreme weather conditions, then it must be allowed to adjust to the difference in environmental conditions before use indoors. Refer to the manual supplied with the battery charger for more information. Celebrity XL www.pridemobility.com...
  • Page 24 Ensure both ends of the charger power cord are inserted fully. How often must I charge the batteries? Two major factors must be considered when deciding how often to charge your scooter’s batteries: All day scooter use on a daily basis. Infrequent or sporadic scooter use. www.pridemobility.com Celebrity XL...
  • Page 25 Do not use wet-cell batteries, which have removable caps. WARNING! Corrosive chemicals are contained in batteries. Use only AGM or Gel- Cell batteries to reduce the risk of leakage or explosive conditions. NOTE: Sealed batteries are not serviceable. Do not remove the caps. Celebrity XL www.pridemobility.com...
  • Page 26 BATTERY Pride Provider for instructions on dis- posal and battery recycling, which is our recommended course of action. BATTERY Figure 13A. Battery Cable Figure 13B. Cable To Termi- Orientation nal Connection www.pridemobility.com Celebrity XL...
  • Page 27 What about public transportation? If you intend to use public transportation with your scooter, you must contact the transportation provider in advance to determine their specific requirements. Celebrity XL www.pridemobility.com...

  • Page 28: Operation

    Pull on the right handgrip to steer your scooter to the right. Move the tiller to the center position to drive straight ahead. To stop, slowly release the throttle control lever. The electronic brakes will automatically engage, bringing your scooter to a stop. www.pridemobility.com Celebrity XL...
  • Page 29 Although the controller is shut down, power will still be supplied to the scooter’s lighting system. If the power down timer feature takes effect, perform the following steps to resume normal operation. 1. Remove the key from the key switch. 2. Reinsert the key and power up your scooter. Celebrity XL www.pridemobility.com...

  • Page 30: Comfort Adjustments

    SEATBACK ADJUSTMENT WARNING! operate your scooter with the seatback in a SEATBACK reclined position. ADJUSTMENT LEVER WARNING! Always keep your back pressed firmly against the seatback while adjusting the angle. Figure 16. Seatback Adjustment www.pridemobility.com Celebrity XL...
  • Page 31 CLAMP-ACTION BOLT seat posts. 7. Install the nut onto the bolt and tighten. LOWER SEAT 8. Tighten the clamp-action bolt. POST 9. Reinstall the rear shroud and the seat. Figure 17. Seat Height Adjustment Celebrity XL www.pridemobility.com...
  • Page 32 MANDATORY! Make sure the positioning belt is properly secured to the scooter and is adjusted for operator comfort. MANDATORY! Inspect the positioning belt for loose or damaged parts before each use of the scooter. If you discover a problem, contact your authorized Pride Provider for maintenance and repair. www.pridemobility.com Celebrity XL...
  • Page 33 The scooter may also produce a fault code. If a fault code occurs, you will need to turn the scooter’s power off, then back on again before proceeding. Celebrity XL www.pridemobility.com...

  • Page 34: Disassembly And Assembly

    5. Unplug the front-to-rear and rear lighting harnesses by squeezing the sides and pulling straight up. See figure 22. 6. Unplug both battery harnesses. Pull each harness straight up. See figure 22. UNLOCKED POSITION LOCKED POSITION Figure 21. Tiller Lock Knob (Locked) Figure 21A. Tiller Lock Knob (Unlocked) www.pridemobility.com Celebrity XL...
  • Page 35 9. Unlock the front wheel by turning the tiller lock knob 90° counterclockwise. See figure 21A. WARNING! After assembly, make FRAME HOOK absolutely certain the tiller lock knob is in the unlocked position before riding your scooter. Figure 24. Frame Separation Celebrity XL www.pridemobility.com...

  • Page 36: Basic Troubleshooting

    Push in the main circuit breaker reset button. See III. “Your Scooter.” Make certain that both battery harnesses and the front-to-rear harness are firmly connected. See VII. “Disassembly and Assembly.” Be sure the power down timer feature hasn’t been activated. See V. “Operation.” www.pridemobility.com Celebrity XL...
  • Page 37 Or, see the previous troubleshooting question for load testing the batteries yourself. If you experience any problems with your scooter that you are not able to solve, immediately contact your authorized Pride Provider for information, maintenance, and service. Celebrity XL www.pridemobility.com...

  • Page 38: Care And Maintenance

    You do not need to lubricate these items, as they are all prelubricated and sealed. CONSOLE, CHARGER AND ELECTRONIC CONTROLLER MODULE Keep these areas away from moisture. Before operating your scooter, allow any of these areas to dry thoroughly if they have been exposed to moisture. www.pridemobility.com Celebrity XL...
  • Page 39 9. Slide the wheel back onto the axle. Make sure that the axle key is in the axle slot. See figure 25. WARNING! Failure to ensure that the axle key is properly installed into the axle slot when mounting the wheel can result in electronic brake failure, personal injury, and/or product damage. Celebrity XL www.pridemobility.com...
  • Page 40 3. Insert a new fuse of the proper rating. WARNING! The replacement fuse must exactly match the rating of the fuse being replaced. Failure to use properly rated fuses may cause damage to the electrical system. Figure 27. Working Fuse Figure 27A. Blown Fuse (Replace) www.pridemobility.com Celebrity XL...
  • Page 41 Your scooter must be disposed of according to applicable local and national statutory regulations. Contact your local waste disposal agency or authorized Pride Provider for information on proper disposal of pack- aging, metal frame components, plastic components, electronics, batteries, neoprene, silicone, and poly- urethane materials. Celebrity XL www.pridemobility.com...

  • Page 42: Warranty

    The battery is covered by a separate six-month warranty, provided by the battery manufacturer. The bat- teries are not warranted by Pride. RECONDITIONED UNITS WARRANTY All reconditioned units are covered by a six-month warranty from Pride effective from the date of purchase. www.pridemobility.com Celebrity XL...
  • Page 43 Circumstances beyond the control of Pride Labor, service calls, shipping, and other charges incurred for repair of the product, unless specifically authorized, IN ADVANCE, by Pride Mobility Products Corporation Repairs and/or modifications made to any part without specific consent from Pride...

  • Page 44: Appendix I - Specifications

    Test conducted at max- imum weight capacity. Includes standard seat. Battery weight may vary based on manufacturer. NOTE: This product conforms to all applicable ANSI-RESNA testing requirements and ISO 7176 EN12184 standards. All specifications subject to change without notice. www.pridemobility.com Celebrity XL...
  • Page 45 18 in. (45.72 cm) Turning Radius 62 in. (157.5 cm) 25.25 in. (64.13 cm) 39.625 - 41.625 in. (100.65 - 105.73 cm) 16 - 17.5 in. (40.64 - 44.45 cm) 3.5 in. (8.89 cm) Figure 28. Scooter Dimensions Celebrity XL www.pridemobility.com...
  • Page 46 N O T E S www.pridemobility.com Celebrity XL...
