Champaign, IL 61826
Swarm (HCAA0300) Replacement Parts
HCAA3350 Complete Wing Set HCAA3356 Decal
HCAA3352 Complete Tail Set
HCAA3354 Fuselage
HCAQ3272 Landing Gear
Star Blazer (HCAA0302) Replacement Parts
HCAA3380 Complete Wing Set HCAP9905 Charger
HCAA3381 Complete Tail Set
HCAA3382 Fuselage
*Requires 6 "C" Alkaline Batteries (not included), and Phillips Screwdriver
WARNING: Read ALL instructions carefully.
Improper use of this product may result in
personal injury or damage to the public.
Step 1. Remove the screw from the fin holder at the back
of the fuselage using a small Phillips screwdriver. Remove
the backing from the adhesive strips at the top rear of
the fuselage.
Assembly and Operation Manual for the
Swarm, Sky Pilot or Star Blazer
HCAP9905 Charger
HCAQ3270 Propeller (2)
HCAQ3300 Propeller (2)
HCAQ3302 Landing Gear
ASSEMBLING YOUR SWARM, SKY PILOT OR STAR BLAZER
Sky Pilot (HCAA0301) Replacement Parts
HCAA3370 Complete Wing Set HCAP9905 Charger
HCAA3371 Complete Tail Set
HCAA3372 Fuselage
WARNING:
CHOKING HAZARD – Small parts.
Not recommended for children under 3 years.
Recommended for ages 10 and up.
Use with adult supervision.
Step 2. Carefully slide the horizontal stabilizer over the fin
holder with the decal side up. Firmly press the stabilizer
onto the adhesive tape.
HCAQ3300 Propeller (2)
HCAQ3302 Landing Gear
