- Page 1 INSTRUCTION MANUAL MOD. LOIRE-P...
-
Page 2: General Warnings
Dear customer: ENG We would like to thank you for choosing one of our products. The product you have just purchased is highly valuable and this is why we kindly invite you to read carefully this brief manual so as you can make the most of your equipment. - Page 3 REGULATIONS ENG To get a perfect combustion regulation, this model presents different types of regulations and air inlets. The working process is as follow: PRIMARY AIR REGULATION It is situated in the front part of the ash pan and it allows regulating the air inlet through the ash pan and the grate towards the fuel.
- Page 4 ARRANGEMENT ELEMENTS REPLACEMENT DEFLECTOR The absence of a deflector causes a big depression with a very fats combustion, excessive wood consumption, and the subsequent overheating of the equipment. To arrange it we need to proceed as follows: INTERNAL SHEETS The internal part of the combustion chamber consists of vermiculite sheets and we should never use the equipment if these sheets have been removed.
- Page 5 The standard frame included in the equipment is detachable in order to make the installation easier. To remove the frame we need to unscrew the 4 bolt placed in the sides (2 in each side.) Datas technicos Loire-P Potencia calorífica 14 kW Rendimiento...
- Page 6 TECHNICAL FEATURES...
-
Page 7: Exploded View Drawing
EXPLODED VIEW DRAWING / N° DESCRIPCION /DESCRIPTION N° DESCRIPCION /DESCRIPTION Regulación aire primario Soporte vermiculita trasera Cajón cenicero Soporte vermiculita lateral Maneta Deflector Frontal Rejilla Cajonera Collarin salida humos Pata Regulación aire secundario Parrilla Conductor aire secundario superior Vermiculita lateral Conductor aire secundario inferior Vermiculita trasera lateral Bisagra... - Page 8 IMPORTANT ENG This product can be installed next to the walls of the room, provided that they meet the following requirements: • To respect a distance of about 5-10 cm. to the wall. • To check that the wall is completely made of brick, fireproof brick blocks, concrete, thin hollow brick, etc., and that they are covered by a material susceptible to support high temperatures.
- Page 9 The data provided in this manual are not binding. The company reserves the right to carry out modifications and improvements without notice.
