INSTRUCCIONES DE INSTALACIÓN,USO Y MANTENIMIENTO
CHIMENEAS METÁLICAS
INSTALLATION, OPERATING AND SERVICING INSTRUCTIONS
METALLIC FIREPLACES
INSTRUCTIONS D'INSTALLATION, D'UTILISATION ET D'ENTRETIEN
CHEMINÉES MÉTALLIQUES
INSTRUÇÕES DE INSTALAÇÃO, USO E MANUTENÇÃO
LAREIRAS METÁLICAS
ISTRUZIONI DI INSTALLAZIONE, USO E MANUTENZIONE
CAMINI METALLICI
Advertisement
Table of Contents
Related Manuals for Bronpi BRASIL Series
Summary of Contents for Bronpi BRASIL Series
- Page 1 INSTRUCCIONES DE INSTALACIÓN,USO Y MANTENIMIENTO CHIMENEAS METÁLICAS INSTALLATION, OPERATING AND SERVICING INSTRUCTIONS METALLIC FIREPLACES INSTRUCTIONS D’INSTALLATION, D’UTILISATION ET D’ENTRETIEN CHEMINÉES MÉTALLIQUES INSTRUÇÕES DE INSTALAÇÃO, USO E MANUTENÇÃO LAREIRAS METÁLICAS ISTRUZIONI DI INSTALLAZIONE, USO E MANUTENZIONE CAMINI METALLICI...
-
Page 2: Table Of Contents
INDEX GENERAL WARNINGS _______________________________________________________________________________________ 15 GENERAL DESCRIPTION _____________________________________________________________________________________ 15 2.1. SPECIFICATIONS ACCORDING TO THE MODEL ______________________________________________________________________ 17 2.1.1. LISBOA-C AND LISBOA-C VISION ______________________________________________________________________________ 17 2.1.2. EBRO AND EBRO-R ___________________________________________________________________________________________ 17 2.1.3. BRASIL AND LISBOA SERIES __________________________________________________________________________________ 17 2.1.4. COMMON TO ALL METALLIC FIREPLACE MODELS _______________________________________________________________ 19 INSTALLATION AND SAFETY INSTRUCTIONS ____________________________________________________________________ 19 3.1. -
Page 3: General Warnings
Bronpi Calefacción, S.L. will not be responsible for the modifications made to the original product without the prior written permission as well as for the use of non-genuine spare parts or pieces. - Page 4 Baffle plate: The baffle plate is a fundamental part for the proper operation of the fireplace. It must be placed in the right position and the fireplace must not be used without the baffle plate. This would invalidate the warranty (see drawings D4, D5 and D6). WARNING! The lack of the baffle plate causes an excessive draw.
-
Page 5: Specifications According To The Model
2.1.3. BRASIL AND LISBOA SERIES Forced ventilation The metallic fireplaces of the Brasil series have a turbine of 225 m / h, while the Lisboa series ones are provided (as standard) with a tangential turbine of 290m / h in order to improve the distribution of the heat through the ventilation of the environment of the installation site. - Page 6 Turbine connection On the right rear side of the fireplace you will find the conductor that connects to the network. It is advisable not to cut it in its length completely since this section is useful when replacing electrical components of the interior. It is fundamental the right connection to the grounding system.
-
Page 7: Common To All Metallic Fireplace Models
The procedure for placing the optional external air intake kit is as follows: At the bottom, under the top, you will find 4 screws that are threaded. Remove the 4 screws. Place the kit as shown in the drawing. Replace the 4 screws previously removed. Connect the air intake to the exterior or selected environment through a 100 mm diameter pipe. -
Page 8: Intervention In Case Of Emergency
3.2. INTERVENTION IN CASE OF EMERGENCY If there is fire in the chimney: Close the loading door. Close primary and secondary air intakes. Put the fire out by using carbon dioxide extinguishers (CO2 powder). Request for the immediate intervention of the fire-fighters. DO NOT PUT THE FIRE OFF WITH WATER. -
Page 9: Connection Of The Fireplace To The Chimney
The minimum diameter must be 4 dm2 (for example, 20 x 20 cm) for chimneys with a diameter below 200 mm or 6.25 dm2 (for example, 25 x 25 cm) for equipments with a diameter higher than 200 mm. A big section of the chimney (for example, diameter of the pipe superior to the one recommended) may results in a volume too large to be heated and, therefore, it can cause difficulties for the proper operation of the equipment. -
Page 10: Outside Air Intake
The fuel allowed is wood. Use only dry firewood (max. moisture content 20%, which corresponds to firewood that was cut two years ago). The length of the logs will depend on the model (you can check the technical features of each model in our web site www.bronpi.com). -
Page 11: Ignition And Normal Operation
It is recommended to use anti-soot envelopes during the operation of the fireplace at least once a week. These envelopes are place directly on the fire and you can buy them in the same Bronpi distributor where you bought your fireplace. -
Page 12: External Cleaning
For this reason, it would be necessary to change them. You can find this spare part in the same Bronpi distributor where you bought your fireplace. - Page 13 Descarga este manual en versión digital. Download this manual in digital version. Télécharger ce manuel en version digitale. Scarica questo manuale in versione digitale. Baixe o manual em versão digital. Para cualquier consulta, por favor, diríjase al distribuidor donde fue adquirido. Please, do not hesitate to contact your dealer for further information.
