  • Page 1 INSTRUCCIONES DE INSTALACIÓN, USO Y MANTENIMIENTO INSERTABLES INSTALLATION, OPERATING AND SERVICING INSTRUCTIONS INSERTS INSTRUCTIONS D’INSTALLATION, D’UTILISATION ET D’ENTRETIEN INSERTS INSTRUÇÕES DE INSTALAÇÃO, USO E MANUTENÇÃO INSERÍVEIS ISTRUZIONI DI INSTALLAZIONE, USO E MANUTENZIONE INSERTI...

  • Page 2: Table Of Contents

    GENERAL WARNINGS ��������������������������������������������������������������������������������������� 31 GENERAL DESCRIPTION ������������������������������������������������������������������������������������� 31 LONDRES AND LONDRES-T VISIÓN SERIES CENTRAL UNIT ����������������������������������������������������������� 34 OPERATION OF THE CAIRO SERIES CENTRALITE �������������������������������������������������������������������� 36 SPECIFICATIONS ACCORDING TO THE MODEL ���������������������������������������������������������������������� 38 2.3.1 MODEL LONDRES, LONDRES VISION, LONDRES-T AND LONDRES-T VISION ��������������������������������������� 38 2.3.2...

  • Page 3: General Warnings

    • On the Cairo series models, you will also receive a box with the inner parts of the combustion chamber (ceramic or vermiculite) to place them before the appliance is switched on. In the case of the Cairo-70 the options for the inside of the combustion chamber are vermiculite or firetek parts.
  • Page 4 (see drawing D2.5). • In Cairo series models, this regulation is located under the door. It is the regulation located on the right of the ash pan (see drawing D2.6). The largest amount of air inlet coincides with the largest side.
  • Page 5 The models of the Paris series incorporate as standard a tangential turbine can be of 225, 290 or 335 m / h, according to the measurement of the model. The operation of the Londres-T model turbine is explained in section 2.1. While the operation of the Cairo series turbine is explained in section 2.2. INSTALLATION, OPERATING AND SERVICING INSTRUCTIONS...

  • Page 6: Londres And Londres-T Visión Series Central Unit

    The installation of the system might be done by skilled labour and qualified under the current rules. WARNING!! The insert (except Paris Series, Londres-T and Cairo Series) must be always connected to electrical network in order to, in case of a high temperature, fans could start and dissipate the heat to the room where it is installed or to any other adjacent room.
  • Page 7 • STANDBY Function: if parameter Stb =1 If the device is OFF, and the temperature is higher than the value of thermostat TSI The device goes in ON automatically • SAFETY Function: if the parameter SIC = 1 If the probe’s temperature is higher than value of thermostat TSI And the fan is OFF in MANUAL Modality The device goes automatically in the Proportional Modality waiting 10 seconds.

  • Page 8: Operation Of The Cairo Series Centralite

    Inbox Controller 120 x 80 x 50 [mm] Applied Rules: EN 60730-1 50081-1 EN 60730-1 A1 50081-2 OPERATION OF THE CAIRO SERIES CENTRALITE This control unit is included as standard in Cairo-70 model and/or optionally purchased Kit-aire-CairoEF, Kit-aire-CairoED and for the Cairo 90 and 110 series.
  • Page 9 STANDBY FUNCTION In the case that the device is OFF, if the probe temperature exceeds 100-120ºC, the device automatically switches to the on state. PROBES DISPLAY The display shows the value read by the probe. If the reading of the probe is below the minimum range of the sensor, the message Lo is displayed. If the probe reading is above the maximum range of the sensor, the message Hi is displayed.

  • Page 10: Specifications According To The Model

    Description Cod. U.M. Suspension time acoustic alarm Fan start time Input configuration S2 Service output configuration Fan safety enabling Air safety enabling Air alarm enabling Enable air valve start function SPECIFICATIONS ACCORDING TO THE MODEL 2.3.1 MODEL LONDRES, LONDRES VISION, LONDRES-T AND LONDRES-T VISION Admission of fresh air Due to the high power of this models of inserts it is advisable to foresee an air intake coming from outside the room to avoid the overheating of the equipment.

  • Page 11: Model Everest

    Electrical connection Disconnect from power before any electrical handling. First of all, we will connect the temperature sensor which is provided with the switchboard to the insert according the attached drawing. Connect the fan with the switchboard and later connect the switchboard and the electrical network (see electrical scheme). Switchboard wiring diagram Probe placement D2.20...

  • Page 12: Model Everest Visión

    2.3.3 MODEL EVEREST VISIÓN This model include on the top an oven with an hermetic oven chamber. The base of the oven is made of ceramic material (it absorbs heat and irradiates it). Heating is produced when the smoke passes through the sides and the upper part of the oven. On the roof of the oven there is one pipe that connects the cooking chamber with the smoke outlet in order to remove the gas generated in the oven.

  • Page 13: All Models Paris Series

    2.3.5 ALL MODELS PARIS SERIES D2.26 PLACING THE DEFLECTOR Due to safety reasons during the transport, the baffle plate is not assembled. You will find it inside the combustion chamber. To place it properly, follow the next steps: BLADE AIR REGULATION If you want to channel air to other rooms, use a hammer to release the 2 hot air outlets at the top of the insert (see diagram D2.27).
  • Page 14 Corner and three-sided models (see drawing D2.31): Remove the rear screws from both the top and bottom frames and pull them out. Remove the screws from the vertical frames and remove frames. Install the insert, fix it and reassemble the frames. D2.31 OUTDOOR AIR INTAKE In the models of the Paris series, it is possible to choose that the entrance of primary air comes from a contiguous place or even from outside...

  • Page 15: Rioja And Coliseo Models

    The profile must be perfectly adjusted either frontally or laterally to the standard frame. D2.40 2.3.7 CAIRO SERIES PLACEMENT OF INTERIOR PARTS OF THE COMBUSTION CHAMBER Optionally, on the Cairo-90 or Cairo-110 models, the interior of the combustion chamber can be made of vermiculite or ceramic. Therefore, together with your appliance you will receive a box with all the parts of the interior of the combustion chamber of the chosen material.
  • Page 16 Before lighting the device, all the parts must be correctly positioned, by following the above steps. ADJUSTMENT OF THE CERAMIC PIECES INSIDE THE COMBUSTION CHAMBER (for Cairo 90 and 110 models) The Cairo series of inserts has the possibility of choosing the interior of the combustion chamber in the VERMICULITE option or the CERAMIC option.
  • Page 17 The baffle plate on 90 and 110 models of the Cairo and Cairo-E series is supported on the side parts and on the rear parts (see drawing D2.46): In the Cairo-D models, after placing the side parts, the set formed by the deflector and the double combustion tube must be introduced.
  • Page 18 D2.51 D2.52 • On the other hand, to connect the CairoD air-kit, the steps to follow are: Screw the two 400 m /h fans to the appliance, one on each side, the screws required for this operation are supplied with the kit. (See drawing D2.53). In order to facilitate this operation it is advisable to remove (unscrew) the air chamber of the device, so you can screw the fan better and then replace it (See...
  • Page 19 EXTERNAL AIR INTAKE D2.62 D2.61 All models of the Cairo series, have the possibility of choosing that the primary Line and secondary air intake comes from an adjacent room (or even from outside the house) or from the same room where Out connection 5-6 the insert is installed.
  • Page 20 Bronpi Calefacción offers for its products. D2.72...

  • Page 21: Installation And Safety Instructions

    INSTALLATION AND SAFETY INSTRUCTIONS The way of installing the insert will affect the safety and the proper operation. For this reason, it is recommendable that the installation is carried out by people who are qualified and informed about the compliance with the installation and safety norms. If an insert is not properly installed it may cause serious damage.
  • Page 22 ** For the fitter The optimum draft for the inserts vary between 12+/-2 Pa (1.0–1.4 mm water column). We recommend checking the technical information of the product. A lower value causes a bad combustion causing carbonic deposits and excessive smoke generation, having leaks and, even worse, an increase of the temperature that could damage the structural components of the insert, while a higher value leads to a too rapid combustion with the heat dispersion through the flue.

  • Page 23: Connection Of The Insert To The Chimney

    CONNECTION OF THE INSERT TO THE CHIMNEY The connection to the insert for the smoke evacuation must be done with rigid aluminized steel pipes or stainless steel pipes. It is forbidden the use of flexible metallic pipes or fibre cement pipes because they damage the safety of the connection because they are subject to jerks and breaks, which causes smoke looses.

  • Page 24: Outside Air Intake

    The fuel allowed is wood. Use only dry firewood (max. moisture content 20%, which corresponds to firewood that was cut two years ago). The length of the logs will depend on the model (you can check the technical features of each model in our web site www.bronpi.com).

  • Page 25: Ignition And Normal Operation

    It is recommended to use anti-soot envelopes during the operation of the insert at least once a week. These envelopes are placed directly on the fire and you can buy them in the same Bronpi distributor where you bought your fireplace.

  • Page 26: External Cleaning

    For this reason, it would be necessary to change them. You can find this spare part in the same Bronpi distributor where you bought your insert.

  • Page 27: Warnings For The Right Recycling Of The Products

    12. WARNINGS FOR THE RIGHT RECYCLING OF THE PRODUCTS 12.1 PACKAGING RECYCLING The function of packaging is to protect your appliance against damage during transport. Actively contribute to the protection of the environment by insisting on environmentally friendly methods of disposal and recovery of packaging materials.
  • Page 28 INSTALLATION, OPERATING AND SERVICING INSTRUCTIONS INSERTS...
