■ Optional battery chargers

D Rapid charging with the BC-160
The optional BC-160 provides rapid charging of the Li-ion battery
pack. Charging time: Approximately 3.5 hours for the BP-232H
The following items are additionally required:
• A power adapter (may be supplied with BC-160 depending on ver-
sion) or DC power cable (OPC-515L/CP-23L)
Optional OPC-515L*
(for power source)
or CP-23L (for 12 V
cigarette lighter socket)
can be used instead of
the power adapter.
*
About OPC-515L
White line:
Black line :
Power adapter
(A different type, or
no power adapter
is supplied,
depending on the
version.)
IMPORTANT!
Ensure the guide tabs
on the battery pack are
correctly aligned with
the guide rails inside
the charger adapter.
BATTERY CHARGING
Battery
Turn OFF
pack
the power
Guide rail
5
Transceiver
Tabs
5
23
