Intermec EasyCoder 401 – User's Manual
PAPER LOAD – TEAR OFF
1
Open the front and right-hand doors.
3
Remove the empty paper core, if any.
4b
In case of paper roll with a 76.2 mm (3 inches) core, first
fit the adapter on the paper supply spool.
2
Turn the printhead lift knob to "Load" position.
4a
Fit a new paper roll on the paper supply spool and push
the roll inwards as far as it will go.
5
Thread the paper underneath the guide shaft behind the
print mechanism.
6
