Chapter 2: Jumpers and Connectors

Speaker-out Pin Header

Connector type: 1x5 5-pin header, 2.0mm pitch
Connector location: JP9
1 5
Pin definition
1 FRONT_L+
3 AGND
5 FRONT_R-
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
Pin definition
2 FRONT_L-
4 FRONT_R+

PS2 Keyboard/Mouse Pin Header

Connector type: 2x4 8-pin header, 2.54mm pitch
Connector location: JP4
2 8
1 7
Pin definition
1 5VSB
3 KDAT_R
5 KCLK_R
7 GND
29
Pin definition
2 5VSB
4 MDAT_R
6 MCLK_R
8 GND
