Chapter 2: Jumpers and Connectors
RTC Pin Header
Connector type: 1x2 2-pin header, 1.25mm pitch
Connector location: J2
2
1
Pin
definition
1
GND
2
VBAT
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
LAN1 LEd Signal Pin Header
Connector type: 2x2 4-pin header, 2.0mm pitch
Connector location: JP8
4
3
2
1
Pin
definition
1
LAN1_ACT_CON
3
LAN1_LINK1G#
26
Pin
definition
2
LAN1_LED_ACT#
4
LAN1_100#_CON
NISE 2400 Series User Manual
