Chapter 2: Jumpers and Connectors

LAN2 LEd Signal Pin Header

Connector type: 2x2 4-pin header, 2.0mm pitch
Connector location: JP5
4 3
2 1
Pin definition
1 LAN2_ACT_CON
3 LAN2_LINK1G#
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
Pin definition
2 LAN2_LED_ACT#
4 LAN2_100#_CON

3G Line-out Pin Header

Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP6
1 3
Pin definition
1 LOUT_L
2 LOUT_R
3 ANGND
27
