Chapter 2: Jumpers and Connectors

dVI-I Connector

Connector type: 24-pin D-Sub, 2.0mm-M-180 (DVI)
Connector location: CON1
1 8
17 24
Pin definition
1 TX2-
3 GND
5 NC
7 DDC_DATA
9 TX1-
11 GND
13 NC
15 GND
17 TX0-
19 GND
21 DDC_DATA_VGA
23 TXCLK+
C1 RED
C3 BLUE
C5A VGADET
MH1 CHASSIS_GND
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
Pin definition
2 TX2+
4 NC
6 DDC_CLK
8 VSYNC_VGA
10 TX1+
12 NC
14 DVI1_PWR (+5V)
16 HotPlugDet
18 TX0+
20 DDC_CLK_VGA
22 GND
24 TXCLK-
C2 GREEN
C4 HSYNC_VGA
C5B GND
MH2 CHASSIS_GND

HdMI

Connector type: HDMI port
Connector location: J4
19
18 2
Pin definition
1 HDMI_DATA2_P_C
3 HDMI_DATA2_N_C
5 GND
7 HDMI_DATA0_P_C
9 HDMI_DATA0_N_C
11 GND
13 NC
15 HDMI_CTRL_CLK_C
17 GND
19 HDMI_HPD
MH1 CHASSIS_GND
MH3 CHASSIS_GND
20
1
Pin definition
2 GND
4 HDMI_DATA1_P_C
6 HDMI_DATA1_N_C
8 GND
10 HDMI_CLK_P_C
12 HDMI_CLK_N_C
14 NC
16 HDMI_CTRL_DAT_C
18 HDMI_PWR
MH2 CHASSIS_GND
MH4 CHASSIS_GND
