Traynor SB200H Service Manual page 4

Specifications
Model:
Type:
Cabinet Impedance (ohms):
Power @ min. impedance (watts):
Minimum Impedance (ohms):
Burst Power - 2 cycle:
Input Channels:
Channel 1 - inputs:
Channel 1 - controls:
Channel 1 - switches:
Channel 2 - inputs:
Line Out (type / configuration):
Line Out Sensitivity (Vrms):
LED Indicators:
Protection:
External speaker output / location:
Other Features:
Dimensions (DWH, inches):
Dimensions (DWH, cm):
Weight (lbs / kg):
SB200H
bass amp
4 ohms
200 watts
4 ohms
250 watts
2
passive 0 dB, active -6 dB
Gain, Bass, Low Mid, High Mid, Treble, Low Expander
Mute, Ground Lift, Line Out Pre/Post EQ
Aux In - 1/4-inch
Balanced Switchable Pre-EQ/Post-EQ, Ground Lift switch
1 Vrms
red,blue protect, power
clip,thermal, overcurrent.
Combi-Jack (1/4-inch/Speakon™) / rear of unit
1/4-inch head phone jack, Tuner out
7.5 x 8 x 1.75
19.1 x 20.35 x 4.5
1.5/0.68
