3.5 inch SCSI Silicon Disk Drive
PC-SDD32V3-SC, PC-SDD64V3-SC,
Thank you for purchasing the CONTEC PC-SDD32V3-SC, PC-
SDD64V3-SC, PC-SDD320V3-SC. Please use this product in
accordance with the procedures described in this document.
About the PC-SDD32V3-SC, PC-SDD64V3-SC,
PC-SDD320V3-SC
- This product is a silicon disk drive interchangeable with
a 3.5-inch hard disks.
- This product provides exceptional robustness against environmental
factors such as vibration and shock, and is suitable for factory
automation applications where high reliability is required.
- Low consumption electric power.
- Exceptionally quiet operation, without the motor noise of a hard disk
drive.
- It can choose from 3 models, 32MB or 64MB or 320MB, according
to a use.
- According to the ware leveling function (flash life span stretching) ),
the rewriting average life spans are about the maximum 1.8 times in
our company so far compared with the product. (Differ depending on
the use condition)
Product Configuration
- PC-SDD32V3-SC or PC-SDD64V3-SC or PC-SDD320V3-SC ...1
- User's Guide (this booklet) ...1
- Screw (M3) ...4
PC-SDD320V3-SC
User's Guide
- 1 -
Advertisement
Table of Contents
Related Manuals for Contec PC-SDD32V3-SC
Summary of Contents for Contec PC-SDD32V3-SC
- Page 1 3.5 inch SCSI Silicon Disk Drive PC-SDD32V3-SC, PC-SDD64V3-SC, PC-SDD320V3-SC User’s Guide Thank you for purchasing the CONTEC PC-SDD32V3-SC, PC- SDD64V3-SC, PC-SDD320V3-SC. Please use this product in accordance with the procedures described in this document. About the PC-SDD32V3-SC, PC-SDD64V3-SC, PC-SDD320V3-SC - This product is a silicon disk drive interchangeable with a 3.5-inch hard disks.
- Page 2 PC-SDD32V3-SC, PC-SDD64V3-SC, PC-SDD320V3-SC Hardware Specifications Hardware Specifications Model PC-SDD32V3-SC PC-SDD64V3-SC PC-SDD320V3-SC Format capacity 32MB 64MB 320MB Bus specification SCSI-2 Terminator *1 OFF (The setting cannot be changed.) Setting the ID address It is possible to set it with the JPSW on the substrate. * factory setting ID 0...
- Page 3 PC-SDD32V3-SC, PC-SDD64V3-SC, PC-SDD320V3-SC External Dimensions 146.5 [mm] Connector Pin Assignment SCSI connector pin assignment Power supply pin assignment Function Function Function TERM PWR RESERVED RESERVED RESERVED RESERVED OPEN - 3 - CONTEC CO., LTD.
- Page 4 PC-SDD32V3-SC, PC-SDD64V3-SC, PC-SDD320V3-SC SCSI ID Setting JP3 JP2 JP1 * A short key (JP1 to JP3) has been installed in one side. Explanation of each JP and CN3 (i) SCSI ID selection setting (JP1 to JP3) OPEN SHORT OPEN SHORT...
- Page 5 PC-SDD32V3-SC, PC-SDD64V3-SC, PC-SDD320V3-SC Write Access Mean Time Before Failure The PC-SDD V series accesses the same sector when overwriting a file. If a write error occurs, a substitute sector is used (290 substitute sectors are provided). Accordingly, the mean time before failure for write access is the time until all of the substitute sectors are used up.
- Page 6 PC-SDD32V3-SC, PC-SDD64V3-SC, PC-SDD320V3-SC Example 2: All 40MB of a 40MB file is overwritten once every 5 minutes This corresponds to case (ii) Average number of writes before failure [No. of accesses] = 4,325,538 Number of writes per hour [No. of accesses/Hour]...
- Page 7 No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document. The information in this document is subject to change without notice.
- Page 8 PC-SDD32V3-SC, PC-SDD64V3-SC, PC-SDD320V3-SC Limited One-Year Warranty CONTEC Interface boards are warranted by CONTEC CO., LTD to be free from defects in material and workmanship for up to one year from the date of purchase by the original purchaser. Repair will be free of charge only when this device is returned freight...
