Contec PC-SDD32H User Manual

2.5 inch silicon disk drive
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

PC-SDD32H, 64H, 128H, 192H,
320H, 500H, 1000H
Thank you for purchasing the CONTEC PC-SDDxH. Please use
this product in accordance with the procedures described in this
document.
Caution
• Use only the mounting screws (M3 x 6) provided with the
product. Longer screws may damage the interior of the product.
About the PC-SDDxH
• This product is a silicon disk drive interchangeable with a
2.5-inch IDE hard disks.
• This product provides exceptional robustness against
environmental factors such as vibration and shock, and is suitable
for factory automation applications where high reliability is
required.
• Low consumption electric power.
• Exceptionally quiet operation, without the motor noise of a hard
disk drive.

Product Configuration

• PC-SDDxH...1
• User's Guide (this booklet)...1
• Mounting screws...1 set (M3 x 6 4pcs., M3 nylon washers 4pcs.)
2.5 inch Silicon Disk Drive
User's Guide
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC-SDD32H and is the answer not in the manual?

Questions and answers

Related Manuals for Contec PC-SDD32H

Summary of Contents for Contec PC-SDD32H

  • Page 1: Product Configuration

    2.5 inch Silicon Disk Drive PC-SDD32H, 64H, 128H, 192H, 320H, 500H, 1000H User’s Guide Thank you for purchasing the CONTEC PC-SDDxH. Please use this product in accordance with the procedures described in this document. Caution • Use only the mounting screws (M3 x 6) provided with the product.

  • Page 2: Hardware Specifications

    PC-SDD32H, 64H, 128H, 192H, 320H, 500H, 1000H Hardware Specifications Hardware Specifications Model PC-SDD32H PC-SDD64H PC-SDD128H PC-SDD192H PC-SDD320H PC-SDD500H PC-SDD1000H Format capacity 32MB 64MB 128MB 192MB 320MB 512MB 1024MB Bus specification ATA (IDE-AT) Transfer rate ATA bus transfer rate 8.0Mbyte/sec(reading / writing)
  • Page 3 PC-SDD32H, 64H, 128H, 192H, 320H, 500H, 1000H Notes Relating to the BIOS Setup Parameters When using a 500MB or smaller product in an AT compatible PC, set the BIOS setup parameter to NORMAL (CHS) mode. If you move this product to a different computer, the product may not operate correctly if LBA mode is set.

  • Page 4: Connector Pin Assignment

    PC-SDD32H, 64H, 128H, 192H, 320H, 500H, 1000H Connector Pin Assignment Signal Function Signal Function RESET- Bus Reset Signal Ground Data Bus Bit 7 Data Bus Bit 8 Data Bus Bit 6 Data Bus Bit 9 Data Bus Bit 5 DB10...
  • Page 5 PC-SDD32H, 64H, 128H, 192H, 320H, 500H, 1000H (i) Size of file being written to is less than 32MB (ii) Size of file being written to is 32MB or more Example 1: All 9.6MB of a 9.6MB file is overwritten once every 5 minutes This corresponds to case (i).
  • Page 6 Copyright 1999 CONTEC Co., LTD. ALL RIGHTS RESERVED No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC Co., LTD. CONTEC Co., LTD. makes no commitment to update or keep current the information contained in this document.

  • Page 7: Limited One-Year Warranty

    PC-SDD32H, 64H, 128H, 192H, 320H, 500H, 1000H Limited One-Year Warranty CONTEC Interface boards are warranted by CONTEC Co., LTD to be free from defects in material and workmanship for up to one year from the date of purchase by the original purchaser.
