PC-HDD/LG User's Guide
Thank you for purchasing the CONTEC PC-HDD/LG. Please use
this product in accordance with the procedures described in this
document.

General Caution

- Do not apply pressing force on the top of cover (See Figure 1. on
page 2).
- Do not cover the breathing hole on the top cover (See Figure 2. on
page 2).
- Do not touch the interface connector pins and the surface of printed
circuit board .
- Hard disk are precision instruments. Be extremely careful in
handling during and after assembly.
- The drive can be easily damaged by shocks or ESD (Electrical
Static Discharge), so any damages applied to the drive after taking
out from shipping package and opening ESD protective bag are
user's responsibilities.
- Be sure to turn off the power of the unit when plugging in or
unplugging connectors.
- Use the mounting screws (M3x5 with sw, w : for screwing the base)
provided with the product. Longer screws may damage the interior
of the product.
- CONTEC bears absolutely no responsibility for use if modified hard
disk.
- This hard disk drive (HDD) has not guaranteed use by continuation
operation and continuation power for 24 hours. When it is used by
continuation operation and continuation power a life fails extremely.
In the case of a 24-hours operation system, use of our company
silicon disk drive (SDD) is recommended.
- The life of a hard disk drive changes with environment or operating
conditions. As a standard, power time (motor-on time) below
250hours/month (below 8 hours/day), disk access time is 20% or
less, it becomes which for 20,000 hours (power time) or five years,
or an early thing.
1
2.5 inch IDE Hard Disk Drive
with Legacy-signal
CONTEC CO.,LTD.
PC-HDD/LG

Advertisement

Table of Contents
loading

Related Manuals for Contec PC-HDD/LG

Summary of Contents for Contec PC-HDD/LG

  • Page 1: General Caution

    - Use the mounting screws (M3x5 with sw, w : for screwing the base) provided with the product. Longer screws may damage the interior of the product. - CONTEC bears absolutely no responsibility for use if modified hard disk. - This hard disk drive (HDD) has not guaranteed use by continuation operation and continuation power for 24 hours.

  • Page 2: Caution Of Usage

    - ATTACH THE DRIVE FREE FROM PRESSING FORCE. DO NOT COVER THIS HOLE Figure 2. Breathing hole caution of PC-HDD/LG COVERING THIS HOLE WILL RESULT LOSS OF DATA. Absolutely No Impact! Excessive impact (greater than 900G;1ms or 120G;11ms), if this hard disk is subjected to, might cause a fatal error that is not recoverable.

  • Page 3: Product Configuration

    - Screw (M3x5, with sw, w) ……4 - Insulation Film……1 - Jumper……1 Note! Check the contents to make sure that you have everything listed above. If you don’t have all the items, Please contact CONTEC. External Dimensions 100 ±0.4 14.25 ±0.25 76.35 ±0.25 8-M3 [mm] 10.14±0.25...

  • Page 4: Master/Slave Settings

    Figure 4. Master/Slave Settings External Dimension Note! Specifications differ slightly depending on the drive manufacturer. Sometimes two drives from two different manufacturers will not operate together. PC-HDD/LG (mfd. by Fujitsu,MHT2020AC) Installation Screw (with sw,w) Installation Part Insulation Film Figure 5.

  • Page 5: Mounting Orientation

    PC-HDD/LG User’s Guide Mounting orientation The drive will operate in all axes(six directions). Horizontal Orientation 1 Horizontal Orientation 2 The gravity direction The gravity direction Vertical Orientation 1 Vertical Orientation 2 The gravity direction Vertical Orientation 3 Vertical Orientation 4...

  • Page 6: Hardware Specifications

    PC-HDD/LG User’s Guide Hard Ware Specifications Item Specification Format Capacity 20Gbyte Bus Specification AT Interface conforming ATA/ATAPI-6 Transfer Speed (Max.) 100MB/sec (Ultra DMA 100) Nominal Supply/Tolerance +5VDC/±5% Consumed Current Spin up (motor on) 7.0W(RMS Typ.) Read/Write 2.1W(RMS Typ.) Idle 0.9W(RMS Typ.)

  • Page 7: Connector Pin Assignment

    No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document. The information in this document is subject to change without notice.

  • Page 8: Limited One-Year Warranty

    PC-HDD/LG User’s Guide Limited One-Year Warranty CONTEC Interface boards are warranted by CONTEC to be free from defects in material and workmanship for up to one year from the date of purchase by the original purchaser. Replacement or repair will be free of charge only when this device is returned to CONTEC freight prepaid with the original invoice.
