Thank you for purchasing the CompactFlash (hereafter abbreviated CF) Memory Card. This product is
a CFA standard CompactFlash.
Follow the procedures in this guide to use the product.
The product consists of the items listed below. Check, with the following list, that your package is
complete. If you discover damaged or missing items, contact your retailer.
Product Configuration List
-
CF Memory Card (One of the following) ...1
[CF-1GB-B, CF-2GB-B, CF-4GB-B or CF-8GB-B]
-
Warranty Certificate ...1
Disposal
When disposing of the product, follow the disposal procedures stipulated under the relevant laws and
municipal ordinances.
Safety Information
This document provides safety information using the following symbols to prevent accidents resulting
in injury or death and the destruction of equipment and resources. Understand the meanings of these
labels to operate the equipment safely.
DANGER indicates an imminently hazardous situation which, if not avoided, will
DANGER
result in death or serious injury.
WARNING indicates a potentially hazardous situation which, if not avoided, could
WARNING
result in death or serious injury.
CAUTION indicates a potentially hazardous situation which, if not avoided, may
CAUTION
result in minor or moderate injury or in property damage.
1
CompactFlash for Fix Disk
CF-1GB-B, CF-2GB-B,
CF-4GB-B, CF-8GB-B
User's Guide
CONTEC CO., LTD.
-
User's Guide (this booklet) ...1
-
Serial number label ...1
CF-1GB-B, CF-2GB-B, CF-4GB-B, CF-8GB-B

Advertisement

loading
Need help?

Need help?

Do you have a question about the CompactFlash CF-1GB-B and is the answer not in the manual?

Questions and answers

Related Manuals for Contec CompactFlash CF-1GB-B

Summary of Contents for Contec CompactFlash CF-1GB-B

  • Page 1 CompactFlash for Fix Disk CF-1GB-B, CF-2GB-B, CF-4GB-B, CF-8GB-B User’s Guide CONTEC CO., LTD. Thank you for purchasing the CompactFlash (hereafter abbreviated CF) Memory Card. This product is a CFA standard CompactFlash. Follow the procedures in this guide to use the product.

  • Page 2: Handling Precautions

    Regardless of the foregoing statements, CONTEC is not liable for any damages whatsoever (including damages for loss of business profits) arising out of the use or inability to use this CONTEC product or the information contained herein.
  • Page 3 CF-1GB-B, CF-2GB-B, CF-4GB-B, CF-8GB-B User’s Guide Features Conforming to the CFA (CompactFlash Association) standard Capable of partitioning internal memory *1 Containing no rotating or moving part as in hard disk drives, thus best suited for applications which require high environmental resistance (to temperature, humidity, vibration, shock) and for continuous operation for extended periods of time.

  • Page 4: Specification

    CF-1GB-B, CF-2GB-B, CF-4GB-B, CF-8GB-B User’s Guide Specification Specifications Item CF-1GB-B CF-2GB-B CF-4GB-B CF-8GB-B Memory 960MB 1920MB 3840MB 7680MB capacity 959MB 1919MB 3839MB 7679MB Bus specification Compact Flash (TYPE I) Host interface ATA standard (ATA3-7)/CFA standard (CF4.1) PIO mode0-4 Multiword DMA mode0-2 Ultra DMA mode0-6 Read *1 40MByte/sec...
  • Page 5 CF-1GB-B, CF-2GB-B, CF-4GB-B, CF-8GB-B User’s Guide About write endurance CF-xGB-B series have a write endurance which limits the number of each memory may be written, cycles due to the characteristic of the memory that is used. For the write endurance when the size of the data written is under 512KB, refer to the “Write endurance”...
  • Page 6 CF-1GB-B, CF-2GB-B, CF-4GB-B, CF-8GB-B User’s Guide Connector pin position list BOTTOM Pinouts *1 Pin Name Pin Name Pin Name Pin Name HA[6] HDB[11] VS2- HDB[3] HA[5] HDB[12] RESET- HDB[4] HA[4] HDB[13] IORDY- HDB[5] HA[3] HDB[14] DMARQ HDB[6] HA[2] HDB[15] DMACK- HDB[7] HA[1] CS1-...
  • Page 7 CF-1GB-B, CF-2GB-B, CF-4GB-B, CF-8GB-B User’s Guide Differences between the CF-xGB-A CF-xGB-B CF-xGB-A Read *1 40MByte/sec 23Mbyte/sec Write *1 15MByte/sec 10Mbyte/sec (Write) Write endurance CF-1GB-B 96,000,000 cycles *2, 2,100,000 cycles or more *3 CF-2GB-B 384,000,000 cycles *2, CF-4GB-B 768,000,000 cycles *2, CF-8GB-B 1,536,000,000 cycles *2 Consumed Sleep...
  • Page 8 CF-1GB-B, CF-2GB-B, CF-4GB-B, CF-8GB-B User’s Guide Copyright 2012 CONTEC CO., LTD. All rights reserved. CONTEC CO., LTD. February 2019 Edition 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan https://www.contec.com/ NA00587 (LYLF603) 02062019_rev3 [03112010] No part of this document may be copied or reproduced in any form by any means without prior written...
