Nitek Etherstretch EL1500CW Installation Manual

EL1500CW
Description
The EL1500CW is another component of NITEK's cutting edge
erstretch
transmit data from IP cameras and other network devices along with power
PoE+) to operate these networked devices over the given wire media.
The EL1500CW system consists of a NEMA4 weatherproof case enclosed transmitter and a
receiver
configuration. The system quickly turns any ordinary RG59 coax cable into a high speed
network communication and PoE pathway.
The EL1500CW is completely transparent to the network thus requiring no IP and MAC
addressing. Simply connect your network devices to the networking ports of the
transmitter and receiver along with existing cabling and the system begins communicating.
LED indicators show the status and speed of network communications and PoE power.
NITEK's EtherStretch
cable distance limitations offering connectivity to devices in locations traditional networking
does not allow. The EL1500CW is ideal for retrofitting existing installations. The units are
constructed of industrial grade RoHS compliant plated aluminum with a corrosion resistant
finish and with the addition of the NEMA4 enclosure makes them extremely durable.
NITEK

INSTALLATION GUIDE

Outdoor IP Cameras Over Coax
Network
solution allows for the utilization of existing cable infrastructure (coax or UTP) to
unit that require very little installation time and absolutely no set up or
EL1500CW reliably extends network communications to overcome
5410 Newport Drive, # 24
Rolling Meadows, IL 60008
Phone: (847) 259-8900
Fax: (847) 259-1300
E-mail: info@nitek.net
®
WWW.NITEK.NET
Extender
—PoE Injector
EtherStretch line. Our Eth-
(PoE &
De Schans 19-21 2a
8231 KA Lelystad
Tel: +31(0)320-2300005
Fax: +31(0)320-282186
E-mail: info@nitek.nl
WWW.NITEK.NL
