Nitek ER8400C Installation Manual

8 Port Wall Mounted IP Video Extender Over Coax
With Built-In Gigabit PoE+ Switch and EtherStretch
The ER8400C is another component of the NITEK cutting edge EtherStretch line. Our EtherStretch solution allows
for the utilization of existing cable infrastructure (coax or UTP) to transmit data from IP cameras and other network de-
vices along with PoE+ power to operate these network devices over the given wire media well beyond the 100m/328ft
networking distance limitation. EtherStretch technology allows you to operate 100Mb Ethernet at over 600 meters.
The ER8400C is a wall mounted eight port power sourcing receiver unit has built-in Layer 2 Gigabit switching capabili-
ties. The unit requires very little installation time and absolutely no set up or configuration. The ER8400C and associ-
ated ET1500C transmitters, up to 8, can quickly enable Coaxial cable to support high speed network communication
and PoE+ transmission to be extended to 500 meters or 1600 feet.
The ER8400C is a fully functional PoE+ Layer 2 switch with IEEE802.3AT power output on each of the 8 EtherStretch
ports and a full Gigabit LAN jack. It allows you to use existing coax cable to install new IP cameras. With EtherStretch
network devices that can extend the network connection to lengths of 500 meters or 1600 feet. The ER8400C require a
small EtherStretch transmitter unit connects at the far end of the cable and allows you to connect any Ethernet device
to the cable and get 100Mb communication.
The ER8400C is completely transparent to the network requiring no IP and MAC addressing. Simply connect your net-
work device to the transmitters network port, connect a new or existing cable to the receiver and the system quickly
begins communicating. LED indicators show the status and data speed of communications along with PoE power con-
firmation.
The NITEK EtherStretch ER8400C reliably extends network communications to overcome cable distance limitations
offering connectivity to devices in locations traditional networking does not allow. The ER8400C is ideal for retro-fitting
existing installations. The wall mounted unit is constructed of robust welded steel casing with a security lock and a built
in cooling and ventilation system.
NITEK

INSTALLATION GUIDE

ER8400C
Description
