16 Port IP Video Extender Over Single Twisted Pair
With Built-In Gigabit Layer 2 Switch with
The ER1651U is another component of the NITEK cutting edge EtherStretch line. Our EtherStretch solution al-
lows for the utilization of existing twisted pair cable infrastructure to transmit data from IP cameras and other net-
work devices over the given copper media well beyond the 100 meter or 328 feet networking distance limitation.
The ER1651U is a Ethernet extending rack mounted sixteen port receiver unit with built-in Gigabit switching capa-
bilities. The unit requires very little installation time and absolutely no set up or configuration. Independently the
ER1651U will work as a fully functional Layer 2 switch. Additionally, the ER1651U and associated ET1551U trans-
mitters (up to 16) can quickly turn ordinary Twisted Pairs into a series of high speed network communication path-
ways. When used with remotely powered ET1551U transmitters, the system will allow for cable runs of up to
500m/1600ft supplying both a network connection and PoE power.
The ER1651U is completely transparent to the network thus requiring no IP or MAC addressing. Simply connect
your network devices to the transmitter network port along with the existing cables to the receiver and the system
quickly begins communicating. LED indicators show the status and data speed of network communications along
with Power and Trouble confirmation.
NITEK EtherStretch ER1651U reliably extends network communications to overcome cable distance limitations
offering connectivity to devices in locations traditional networking does not allow. The ER1651U is ideal for retro-
fitting existing installations. The rack mounted unit is robustly constructed of molded steel casing with appropriate
built-in cooling and ventilation.
03262013
NITEK
INSTALLATION GUIDE
ER1651U
Description
5410 Newport Drive, # 24
Rolling Meadows, IL 60008
Phone: (847) 259-8900
Fax: (847) 259-1300
E-mail: info@nitek.net
®
WWW.NITEK.NET
EtherStretch
RoHS
COMPLIANT
2002/95/EC
De Schans 19-21 2a
8231 KA Lelystad
Tel: +31(0)320-230005
E-mail: info@nitek.nl
WWW.NITEK.NL
Advertisement
Table of Contents
Related Manuals for Nitek ER1651U
Summary of Contents for Nitek ER1651U
-
Page 1: Installation Guide
100 meter or 328 feet networking distance limitation. The ER1651U is a Ethernet extending rack mounted sixteen port receiver unit with built-in Gigabit switching capa- bilities. The unit requires very little installation time and absolutely no set up or configuration. Independently the ER1651U will work as a fully functional Layer 2 switch. -
Page 2: Important Safety Instructions
Important Safety Instructions Read all Safety Instructions. Keep the Instructions for future reference. Be sure to HEED all Warnings. Follow ALL instructions. DO NOT use this device or any of the equipment described, near water. Clean this device ONLY with a dry cloth. DO NOT block any ventilation openings. -
Page 3: Installation Considerations
Parts of the ER1651U (Front Panel) Installation Considerations Wire and Cable Recommendations: The ER1651U is designed for use with up to sixteen (16) Pairs of Twisted Wire, compatible with all Category cabling (Cat3, Cat5, Cat5e and Cat6). The quality of which must be consistent with any reasonably serviceable cable condition. -
Page 4: Device Mounting Options
Ears Ears The ER1651U is to be rack mounted. Use the included mounting ears when rack mounting the unit, and be sure to follow these guide lines. a. Operating Ambient - Do not install the unit in an assembly where the ambient temperature could exceed 52°C (125°F). -
Page 5: Installation And Setup
The aggregate PD data is transmitted to the greater LAN or WAN via the gigabit LAN port labeled and located on the back of the NITEK PSE. The ER1651U is a Layer 2 switch and with 1 “smart” LAN port. If the Trouble LED is flashing slowly it will indicate that the network has a loop in it and data is cascading. - Page 6 Network Switch, NVR or Server NVR or Server 115/230 IP Camera NITEK PS48 IP Camera Transmitter-end Installation ET1551U Units System At the camera location securely mount the transmitter. Find the twisted pair cable from the head-end and make sure it is properly terminated. Connect the wires of the twisted pair cable to the “Link Port”...
- Page 7 IP cameras and other PoE devices, when powered directly from a 48VDC supply. Either use the PS48 Power Supply from Nitek or other 48VDC power supply to operate the units. The illustration below shows the use of the PS48 supply. Other DC power supplies can be used with the supplied power connector if desired but must be 48 to 56 VDC for proper operation.
-
Page 8: Unit Dimensions
Unit Dimensions 19.0 17.3 Top View NITEK ER1651U ETHERSTRETCH RECEIVER 100 Mbps 1000 Mbps 10 Mbps 100 Mbps PORT PWR 10 Mbps 100 Mbps POWER 10 Mbps PORT PWR TROUBLE 9 10 11 12 13 14 15 16 Front View... - Page 9 Connectivity LED Status Trouble LED Solid= Temperature Alarm Flashing= Network Loop Warning 568B Pinout Termination 8 Position Degson Wire Termination ER1651U 16 Channel Ports TCP/IP TCP/IP TCP/IP TCP/IP...
-
Page 10: Troubleshooting
Troubleshooting PROBLEM POSSIBLE CAUSE No video/data Check camera and ER1651U/ET1551U device connections. Check Twisted Pair wire condition and connector terminations. Check that the camera is powered. Check that supplied camera power meets manufacturer’s specifications. Check cable that cable distances do not exceed PoE capabilities. -
Page 11: Limited Warranty
NITEK with shipping charges prepaid. NITEK shall pay for the return of the product to the purchaser if the shipment is to a location within the U.S.A. The purchaser shall be responsible for paying all shipping charges, duties and taxes if the product is returned from a location outside the U.S.A.
