PRO SERIES
3600 / 4600
TM
Pouch Laminators
Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO 3600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GBC PRO 3600

Summary of Contents for GBC PRO 3600

  • Page 1 PRO SERIES 3600 / 4600 Pouch Laminators Instruction Manual...
  • Page 2 Rear of machine Pouch exit outlet Main power switch Cable socket Pouch insertion slot Power cord Control panel...
  • Page 3 Display Panel - Indicate that the machine is READY TEMPERATURE - Indicate the ready to laminate. temperature setting. HOT - Indicate that the HOT function SPEED - Indicate the speed setting. is selected. - Indicate that the roller is COLD - Indicate that the COLD function moving in reverse revolution.

  • Page 4: Important Safeguards

    General safeguards Special notice documents. Thank you, for your recent purchase of a GBC Pouch Laminator. laminator other than pouches/documents. Your new laminator may emit a slight odour during the initial stage of operation. It is normal and will diminish after several from falling and possibly causing personal injury and hours of operation.
  • Page 5 Technical specifications GBC PRO SERIES 3600 GBC PRO SERIES 4600 220-240V / 50~60Hz / 1050W / 6.0A 220-240V / 50~60Hz / 1050W / 6.0A Electrical Machine Dimensions 540 x 271 x 112 mm 691 x 271 x 112 mm 15.0 kg Machine Weight 20.0 kg...
  • Page 6 Finishing lamination Operation, cold lamination Connect power cord to appropriate power source. Press and hold POWER button for one second and “COOL” Press the power switch on the back of the laminator and symbol appears on the LCD. press the POWER button for 1 second to turn on the After the roller cool down (below 65°C), the laminator will machine.
  • Page 7 Lamination Guide Setting with Carrier Setting without Carrier Material Film thickness Speed Speed Temperature Temperature 75 ~ 100 Micron 100°C 130°C Copy Paper 125 ~ 150 Micron 120°C 130°C 175 ~ 250 Micron 120°C 140°C 300 ~ 350 Micron 130°C 75 ~ 100 Micron 100°C 130°C...
  • Page 8 ACCO BRANDS ASIA PTE LTD 5A Toh Guan Road East #06-03 Singapore 608830 Tel: +65 6776 0195 Fax: +65 6779 1041 singapore.webmaster@acco.com Ref:PROSERIES-3600-4600/SG/V1/220415...

This manual is also suitable for:

Pro 4600
