Olympia AD200 User Manual

Olympia AD200
Cree® XP-G LED
Flashlight

User Guide

Congratulations on your purchase of the
Olympia AD200 Cree® XP-G LED high-
performance flashlight. This product is designed
to provide you with the best possible functionality.
The AD200 utilizes Cree
is geared for optimum brightness and efficiency.
It's constructed in aircraft-grade aluminum with
premium Type II hard anodized, anti-abrasive
Head Body
finish. The lightweight, compact design makes
it a functional light for multiple uses including
hunting, hiking, camping, caving, general
household use, recreational activities, rugged
Body
sports or emergency situations. Please take a
few moments to read this user guide to ensure
that you get the best performance and years of
trouble-free service.
Head

Product Description

Head
Body

Battery Installation

Body
1. Unscrew the tail switch cap and insert 2xAA
Alkaline non-rechargeable or rechargeable
*batteries. The (+) terminal on the batteries
should face toward the flashlight's head.
2. Replace the tail switch cap and be sure to
tighten snugly, but do not over tighten as this
Head
Clip
could strip the threads in the cap. Turn on the
flashlight as indicated in any of the options
listed in the table that follows. Note: If the tail
cap is not tightened snugly; the flashlight
will not turn on.
Head
Body Body
3. When the battery life is nearly depleted, your
flashlight will blink to indicate new batteries are
needed.
Clip
Body Body
Head
*Non-rechargeable batteries included

Flashlight Operation

Your Olympia AD200 Cree® XP-G LED high-
performance flashlight has a push-button tail
switch for on/off operation and is equipped with
1) Momentary and 2) Continuous light options.
It also has 5 light modes to suit your varied
needs. See table instructions to access these
functionalities:
Tail
Clip
Cap
Switch
LED technology that
®
Lanyard
Hole
Clip
Tail
Clip
Cap
Switch
Lanyard
Hole
Clip
Tail Tail
Clip
Cap Cap
Switch Switch
Lanyard Lanyard
Hole Hole
Clip
Momentary-on
Lighting
Continuous
Lighting

Lighting Modes

Accessing the 5 Lighting Modes

High Beam
Mid Beam
Low Beam
Strobe
Tail
SOS
Cap
Switch

Memory function

Lanyard
Your Olympia AD200 Cree® XP-G LED flashlight
Hole
automatically memorizes the last light setting/
mode used when the flashlight next is turned on.
i.e., after being in any one of the five light settings
(High Middle

the last one used will be memorized.

Maintenance and Precautions

1. Do not disassemble the sealed head. Doing
so can cause damage to the flashlight and will
Tail void the warranty.
Cap
2. Use high-quality batteries or you run the risk
Switch
of the flashlight being damaged by electrolyte
leakage or battery breakage.
3. If the flashlight will not be used for a long time,
remove the batteries to avoid damage caused
Lanyard
Hole
from battery leakage.
4. Lubricate the O-rings regularly using a
Q-tip . Apply a small dab of silicone grease
®
or petroleum jelly to the contacts to prevent
corrosion. Doing so will keep the flashlight
properly sealed against water. If the O-rings are
damaged after prolonged use, replace them.
5. Clean the flashlight contacts periodically
especially if the light flickers or does not light
Tail Tail
up. There are different reasons for a flickering or
Cap Cap
Switch Switch
non-working light:
A: The batteries may need to be replaced.
Solution: Replace old/defective batteries with
new ones (be sure to double check correct
installation of + and - terminals).
Lanyard Lanyard
Hole Hole
B: The threads, PCB board contact or other
contacts are dirty.
Solution: Use a Q-tip
of alcohol to clean the contact points.
If the above methods do not work, please refer to
the warranty policy listed in this user guide.
Warning
!
The AD200 is a high-intensity lighting device and
capable of causing eye damage. Please avoid
shining the light directly into the eyes.

Lighting Operation Modes

Press the push-button tail switch
half-way to activate the light
momentarily.
Press the tail switch push-button to
completely turn on the flashlight.
The light will stay on until the push-
button is turned off.
There are five types of light output:
HighMiddle
LowStrobeSOS
Press the tail push-button to switch
to each mode
Press the push-button tail
switch once
Press the push-button tail
switch twice
Press the push-button tail
switch 3 times
Press the push-button tail
switch 4 times
Press the push-button tail
switch 5 times
Low Strobe SOS) for 3 seconds,
  
to apply a tiny amount
®
