USER GUIDELINE
Thank you for choosing MOON LUXEIUM series headlight!
*For using this product safely and conveniently and keeping it
well-preserved, please read this manual carefully before using.
Please save this manual for future reference.
*Due to the improvement of the product, the product you bought may
not be exactly in accordance with the introduction of this manual. We
apologize for that.
SPECIFICATION
*1 pc CREE XP-E LED
*Rechargeable lithium polymer battery ( 3.7V 550mAh)
*USB rechargeable
*Water resistant headlight with durable aluminum alloy body
*6 modes : Over drive / High / Standard / Flashing / Strobe / SOS
*Quick release handlebar mount (fits 20-40mm)
*Low battery, charging and fully charged indicator
*Automatic fully charged cut-off system
*High precision optical lens
CONTECTS INCLUDED
CONTENTS:
* LX-100
* Lithium polymer battery
* USB cable
* Handlebar rubber strap
* Rubber base
LIGHT OPERATION
1. Press the power button to choose the modes:
In this method three modes are cycle.
Over drive
High beam
Standard
2. Fast press two times the power button to change into the strobe
and flashing modes.Fast press two times back to the first cycle.
Flashing
Over drive
Fast press
2 times
Strobe
High beam
Standard
SOS
3. Press and hold the on / off button around 0.5 second to turn off.
®
HOW TO MOUNT THE HEADLIGHT
1. Choose the strap to fit in the bar.
2. Make sure the strap is click in place of the hook.
3. Hold the light on the handle bar.
4. Wrapping rubber strap around bar and stretching strap around hook to secure.
1.
RS-A
20 - 25 mm
2.
Power button
3.
Power button
PRESS
USB cover
BEAM ADJUSTMENT
To adjust the horizontal beam, spin the headlight left to right for your
best side to side beam angle. To adjust the vertical beam angle,
Power button
loosen the mounting and rotate the light up and down to your best
vertical beam angle, then tighten the mounting.
Fast press
2 times
!
The beam is widely dispersed, besides its high brightness. To prevent
from blinding the oncoming vehicles on the public roads, you'd better
adjust the angle downward.
Power button
PRESS
Hold 0.5 sec
RS-B
27 - 40 mm
Rubber strap
(Make sure the strap is click in place of the hook.)
Base cover
WRAPPING
THE BATTERY REPLACEMENT
RELEASE
Hold
RELEASE
Hold
Battery release
1.Twist the screw anti-clockwise until release the base cover & rubber pad.
2.Use two finger to hold the light body when release the battery from the
light.
INSTALL THE BATTERY
UPSIDE DOWN
Hold
Hold
INSTALL
Battery installation
1. Do not up side down the slot.
2. Align the slot until it clicks into place.
3. Fold up the battery install into the light.
4. Twist the remain wire into the light of the remain sapce.
5.Twist the screw clockwise until install the base cover.
RELEASE
Battery
ALIGN
INSTALL
Battery
