moon COMET-X PRO User Manualline

USER GUIDELINE
Thank you for choosing MOON light!
*For using this product safely and conveniently and keeping it
well-preserved, please read this manual carefully before using.
Please save this manual for future reference.
*Due to the improvement of the product, the product you bought may
not be exactly in accordance with the introduction of this manual. We
apologize for that.
SPECIFICATION
*1 pc (30 chips) COB high brightness red LED
*CNC Aluminium heat sink casing
*Auto safe mode
*Mode memory function
*Rechargeable lithium polymer battery (3.7V 500 mAh)
*7 modes: Mode1 / Mode2 / Mode3 /
FL1 / FL 2 / FL 3 / DAY FLASH (DOUBLE BLAST)
*Quick release universal bracket RB-22
(fits all round bars and AERO style bars)
*Low battery, charging and fully charged indicator
*Automatic fully charged cut-off system
*Side visibility
*Water resistant (IPX 4)
CONTENTS INCLUDED
Contents:
*COMET-X PRO
*RB-22 (Universal bracket)
*2 O-rings for mounting:
RS-G (fits 20-35mm diameters)
RS-H (fits 35-52mm diameters)
*BK-21 (Belt clip)
*RB-21 (Saddle rail bracket)
*USB-WP (Water resistant USB cable)
Optional accessories:
*RB-19 (Rear rack mount bracket)
*RB-23 (Helmet bracket)
*USB-RM-1200 (USB remote control 1200mmL)
LIGHT OPERATION
Low battery status
* Steady blue
Auto safe mode
* Flashing blue
1. Double click the power button to toggle between the steady and
flashing modes.(With mode memory, the light will resume previous
mode upon next usage.)
Double click
FL1
FL2
FL3
DAY FLASH
(DOUBLE BLAST)
2. Press and hold the power button about 1 second to switch off.
(With mode memory, the light will resume previous mode upon next
usage.)
HOW TO MOUNT THE LIGHT
®
1. Choose the strap to fit in the bar.
2. Make sure the strap is clicked in place of the hook.
3. Hold the light on the handle bar/seat post.
4. Wrapping rubber strap around bar and stretching strap around hook to secure.
5. Slide the light forward onto bracket until it clicks into place.
6. Press down release lever to remove.
26-35 mm
RS-G
20-35 mm
Install
Pull
Power button
Indicators
Mode1
Mode2
Mode3
7. Adjust the horizontal beam angle when mounted on the handle bar
loosen the screw knob and spin the light left to right for your preferred
angle, then tighten the screw knob to secure the light in place.
20-26 mm
26-35 mm
35-52 mm
RS-H
35-52 mm
Release
Install
click
Release
Press
Install
click
1. Slide tail light forward onto belt clip until it clicks into place.
2. Press down release lever to remove.
HOW TO MOUNT THE LIGHT
RELEASE
Method 1
Press
1. clockwise
INSTALL
click
3.
Method 2
ADJUST
ADJUST
1. Loosen the screws in the saddle bracket with the Allen key.
2. Clamp the bracket onto the saddle rail.
3. Align the screw holes, using the Allen key to tighten the bracket.
4. Slide light forward onto bracket until it clicks into place.
5. Press down release lever to remove.
6. Twist the light body to adjust the vertical angle.
Method 2
Method 1
2.
anticlockwise
ADJUST
4.
ADJUST
INSTALL
INSTALL
