Insert the Batteries in the Transmitter

Insert 8 AA batteries (not included) into the 2.4 GHz transmitter. Pay attention to the correct polarity. Check the pow-
er level of the batteries on the voltage display. Change the batteries immediately when the voltage is too low and the
acoustic warning signal sounds.

Inserting the flight battery

Slide the battery plate including the flight battery into the battery rails of the front porch and secure it with O-rings.
Sliding in the battery plate. Securing the battery plate with O-rings.

Transmitter settings

Do not change any settings or the programming of the transmitter. All settings are optimally configured ex works.
Any changes whatsoever are at your own risk. Heli Professional will not accept responsibility for damages or any
secondary failures.
Two throttle curves are programmed ex works: a hovering/normal flight curve (switch position "Normal") and a
3D/stunt flight curve (switch position "3D").
Hovering/Normal Flight Mode (Pitch Range -5°/+12°): When switching
on the transmitter or starting the model, always put the pitch stick in
its lowest position. If you tilt the pitch stick slowly upwards, the collec-
tive pitch angle of the main blades will increase, and the helicopter will
start to climb. If you lower the pitch stick, the collective pitch angle of
the main blades will decrease and the helicopter will start to descent.
www.heli-professional.com 6
