Page 1: Operating Instructions
Model No MS0801-E01 Operating Instructions Thanks for purchasing our product. Please be sure to read this instruction manual carefully before using our product. - Page 3 HDMI input supports HDMI1.3b and HDMI1.4 3D. On the Analog Component Video and Analog Composite Video channels, If the resolution of the input signal is 480i or 576i, MS0801-E01 will deinterlace the resolution to 480p or 576p respectively. MS0801-E01 has the ability of equalization and amplification to ensure HDMI signal's transmission through long cable without quality loss.
-
Page 4: Table Of Contents
Contents ....................1 HDMI Switch ■ Product Overview..................1 ■ Features....................1 ■ Package Contents..................3 ■ Connections and Operations..............3 ■ Specifications .................... 3 ■ Panel Descriptions ..................4 ■ IR Controller Descriptions ................. 5 ■ Timing Table ..................... 6 ■... -
Page 5: Hdmi Switch
Support high definition resolutions 1080P, 1080I, 720P and standard video format. Double switching modes, IR remote and manual. HDMI V1.3 / HDMI V1.4 with 3D. Notice Grandbeing Inc. reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. Page 1... - Page 6 Warning To reduce the risk of fire, electric shock or product damage: 1. Do not expose this apparatus 6. Clean this apparatus to rain, moisture, dripping or only with dry cloth. splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
-
Page 7: Package Contents
2) Connect the HDMI outputs (such as HD-LCD, HD-DLP) into MS0801-E01. 3) Power on the input source you want to show. 4) Connect the power supply adaptor into MS0801-E01 and turn on the display you want to watch. 5) Use remote or push the button to choose input source. -
Page 8: Panel Descriptions
Panel Descriptions ■ Upper Panel 1. YPbPr1 Input port with L/R Audio. 2. YPbPr2 Input port with L/R Audio. 3. AV1 Input port with L/R Audio. 4. AV2 Input port with L/R Audio. 5. VGA input port. 6. Audio of VGA port. 7. -
Page 9: Ir Controller Descriptions
11. HDMI3 — Press the button to switch to HDMI3 channel. 12. AUTO COPY — Press the button to copy the EDID from TV to MS0801-E01 13. 1080P 8CH — Press the button to activate EDID as 1080P/8 audio channel/3D TV supported... -
Page 10: Timing Table
Timing Table ■ 480i, 480P, 576i, 576P, 720P@[50/60], YPBPR/HDMI 1080i@[50/60], 1080P@[50/60] 800x600@60, 1024x768@60, 1280x1024@60, 1440 x900@60, 1400 x1050@60, 1600 x1200@60, 1920 x1080@60, 1920 x1200@60 Typical Application ■ Page 6... -
Page 11: Maintenance
Maintenance ■ Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzine to clean this unit. Product Service ■ ● Provided Service 1) Damage Requiring service: The unit should be serviced by qualified service personnel if: The DC power supply cord or AC adaptor has been damaged;... -
Page 12: Warranty
Warranty If your product does not work properly because of a defect in materials or workmanship, Grandbeing Company (referred to as “the warrantor”) will, for the length of the period indicated as below, (Parts (1) Year, Labor(90) Days) which starts with the date of original purchase (“Limited Warranty period”), at its option either (a) repair your product with new or refurbished parts, or (b) replace it with a new or a refurbished product. - Page 13 consumer controls, improper maintenance, power line surge, lightning damage, modification, or service by anyone other than a Factory Service Center or other Authorized Service, or damage that is attributable to acts of God. 2) There are no express warranties except as listed under “limited warranty coverage”.
- Page 15 Grandbeing Technology Co., Ltd. Address: 6C, Jialitai Building, No. 6 Yanshan Road, Nanshan District Shenzhen, P.R. China Tel: 86-755-26678449 Fax: 86-755-26678549 Post Code: 518067 www.grandbeing.biz...
