Page 1: User Manual
User Manual SW0401-N073-000 4 x 1 HDMI Switcher Version: V1.0.0... -
Page 2: Important Safety Instructions
Important Safety Instructions Note: In case of any content change, we are sorry for no further notice. Warning: To reduce the risk of fire, electric shock or product damage: 1. Do not expose this apparatus 6. Clean this apparatus to rain, moisture, dripping or only with dry cloth. -
Page 3: Table Of Contents
Table of Contents Introduction ....................2 Overview ....................2 Features ....................3 Package Contents ..................3 Specifications .................... 4 Panel ......................6 Hardware Installation ..................8 Operation ......................9 Front Panel ....................9 Remote Control ..................9 EDID Management ..................11 Firmware Upgrade .................. -
Page 4: Introduction
Introduction Overview The SW0401-N073-000 is a 4 by 1 HDMI switcher, a perfect solution for managing multiple sources. It provides four inputs for direct connection of HDMI devices, which gives you a high performance connection between four sources and a sink without signal loss. Simply pressing one button to select your desired HDMI source for display on the HDTV. -
Page 5: Features
HDMI 1.4 with 3D HDCP compliant EDID management Firmware updates via Mini-B USB Package Contents 1 x HDMI Switcher SW0401-N073-000 1 x Remote 1 x 5V 2A DC Power Supply 2 x Mounting Ear ... -
Page 6: Specifications
Specifications Video Input 4 x HDMI Output 1 x HDMI Input/ output Signal Type HDMI: HDMI 1.4 with HDCP HDMI: 480i,576i,480p,576p,720p@50, 720p@60,1080p@24,1080i@25, Input/output Resolution Support 1080i@30,1080p@30,1080p@50, 1080p@60, 4K x 2K@30 Maximum Pixel Clock 297 MHz Input Video Signal 0.5~1.5 volts p-p Video Impedance 100 ohms Audio... - Page 7 General 32°F to 95°F (0°C to 35°C) Operating Temperature 10% to 90%, non-condensing -4°F to 140°F (-20°C to 70°C) Storage Temperature 10% to 90%, non-condensing Human-body Model: ±8kV(Air-gap discharge)/ ESD Protection ±4kV(Contact discharge) Device: 123mm × 90mm × 28mm /4.84’’ x 3.54’’ x 1.1’’ Dimensions (W x H x D) Giftbox: 430mm x 238mm x 75mm /16.93’’...
-
Page 8: Panel
Panel Side & Front Panel Name Description HDMI 1~4 Connect to HDMI sources Press to scroll between connected Select Button sources Indicators Lit when source selected IR Receiver Sensor Accept IR signal... - Page 9 Rear Panel Name Description Power 5V 2A DC power input EDID DIP Switch Adjust EDID settings Audio Output Connect to an audio system HDMI OUT Connect to an HDMI sink Mini USB Update the firmware...
-
Page 10: Hardware Installation
Connect the HDMI input sources (such as DVD Player) to SW0401-N073-000. Connect the HDMI sink (such as HD-LCD) to SW0401-N073-000. Connect the AV Receiver to SW0401-N073-000. Power on all the devices. Control SW0401-N073-000 by pressing select button in the front panel or the provided remote. HDMI Audio Side... -
Page 11: Operation
Operation The SW0401-N073-000 can be controlled through the front panel button or remotely using the remote provided. Front Panel Select the source by pressing the Select button, indicators will indicate the selection. Remote Control There are two buttons on the remote to select the HDMI input source... - Page 12 Button IR Code 0015 0040 0015 0015 0015 0015 0015 0015 0015 0015 0015 0040 0015 0015 0015 0040 0015 0015 0015 0040 0015 0040 0015 0040 0015 0040 0015 05ED 0155 0055 0015 0E47 0000 006D 0022 0002 0155 00AA 0015 0015 0015 0040 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0040 0015 0015 0015 0040 0015 0040 0015 0040 0015 Left...
-
Page 13: Edid Management
EDID Management The HDMI Switcher features an EDID copy mode that can be used when the EDID’s do not meet the installation requirements. Note: The change doesn’t take effect until you restart the HDMI Switcher. Position Functions Automatically copy HDMI Sink's EDID to all HDMI Inputs, if failed, the EDID of all HDMI inputs won’t change. -
Page 14: Firmware Upgrade
Firmware Upgrade Warning: Do not turn off power during upgrade processing, otherwise it may cause damage to the device. Step 1. Double click EPFlash.exe on your computer. Step 2. Click OpenFile button, browse for the .hex file, and click Open. - Page 15 Step 3. Click PROGRAM. Step 4. The firmware upgrade is completed.
-
Page 16: Product Service
Product Service Maintenance Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzine to clean this unit. Provided Service 1. Damage Requiring service: The unit should be serviced by qualified service personnel if: The DC power supply cord or AC adapter has been damaged; ... -
Page 17: Warranty
Warranty If your product does not work properly because of a defect in materials or workmanship, Grandbeing Company (referred to as “the warrantor”) will, for the length of the period indicated as below, （Parts (1) Year， Labor(90) Days） which starts with the date of original purchase (“Limited Warranty period”), at its option either (a) repair your product with new or refurbished parts, or (b) replace it with a new or a refurbished product. - Page 18 Service, or damage that is attributable to acts of God. 2. There are no express warranties except as listed under “limited warranty coverage”. The warrantor is not liable for incidental or consequential damages resulting from the use of this product, or arising out of any breach of this warranty.
-
Page 19: Glossary
Glossary Acronym Complete Term Digital Visual Interface EDID Extended Display Identification Data High Definition HDCP High-bandwidth Digital Content Protection HDMI High Definition Multimedia Interface HDTV High Definition Television Infrared Radio Corporation of American Tip Ring Sleeve... - Page 20 Grandbeing Technology Co., Ltd. Address: B-301, Science and Technology Building Phase11, 1057 Nanhai Rd, Nanshan District, Shenzhen, P.R.China Tel: 86-755-21620566 Fax: +86 755-21620564 Post Code: 518067 www.grandbeing.biz...
