HDMI Switch
SW0301
Model No.
Operating Instructions
Dear customer
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or adjusting
this product. Please keep this manual for future reference.
FEATURES
Easy to Use: Install in seconds, no need for setting.
Switching: User could select anyone of the three HDMI inputs to the output.
Signalling rates up to 1.65Gbps in support of UXGA and 1080P display.
Each port supports HDMI or DVI inputs.
8dB receiver equalization to compensate for 5m HDMI cable losses.
3dB driver pre-emphasis to compensate for PCB losses.
NOTICE
Grandbeing Inc. reserves the right to make changes in the hardware, packaging
and any accompanying documentation without prior written notice.
１
Grandbeing
（P/N of this Instructions is INSSW0301）
Operating Instructions
®
GRANDBEING
®
Advertisement
Table of Contents
Related Manuals for Grandbeing SW0301
Summary of Contents for Grandbeing SW0301
- Page 1 8dB receiver equalization to compensate for 5m HDMI cable losses. 3dB driver pre-emphasis to compensate for PCB losses. NOTICE Grandbeing Inc. reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. ®...
- Page 2 10) REFER ALL SERVICING TO QUALIFIED SERVICE PERSONNEL. INTRODUCTION Grandbeing’s SW0301 is a three-way HDMI selector. User could select any HDMI input by a remote or switch button on the front panel of the main unit. SW0301 has the functions of equalization and pre-emphasis.
- Page 3 Remote P/N_RMT003 2 AA alkaline batteries P/N_BAT005 * HDMI cables are optional. PANEL DESCRIPTIONS Front Panel 1) Power Switch. 2) Power indicator. 3) IR window. 4) Input status indicator. 5) Output status indicator. 6) Source selection button. ® ３ GRANDBEING...
-
Page 4: Specifications
2) Connect the HDMI device into the HDMI Output slot in the back of SW0301. 3) Insert the DC side of 5v power supply into SW0301 and then connect the AC side of the power supply into the wall outlet. -
Page 5: Product Service
WARRANTY If your product does not work properly because of a defect in materials or workmanship, Grandbeing Company (referred to as “the warrantor”) will, for the （Parts (1) Year， Labor(90) Days） length of the period indicated as below, which starts with the date of original purchase (“Limited Warranty period”), at its option... - Page 6 The items listed are not exclusive, but are for illustration only.) 3) PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE YOUR RESPONSIBILITY. ® ６ GRANDBEING...
- Page 7 Operating Instructions Grandbeing Technology Co., Ltd 6C, Jialitai Building, No.6 Yanshan Rd. Nanshan District, Shenzhen , P.R. China Post Code:518067 Tel: 86-755-26678449 Fax:86-755-26678549 Email:Sales@grandbeing.com, lauarthur@163.com Website:http://www.grandbeing.com ® ７ GRANDBEING...
